Preparation
This section explains the preparation and resources required to install the Smart Card feature.
Configuration Checklist
The following items are required to complete the installation:
StatusSummary
1. Obtain the IP address or Host Name for each applicable Windows Domain Controller.
2. If Domain Controller Certificate validation is required, obtain the DC certificate for each ap-
plicable controller, including all intermediate certificates up to the root certificate.
Note
This procedure typically is required only for Smart Card.
3. If Online Certificate Status Protocol (OCSP) is available, obtain the IP address or Host Name
for the OCSP server.
4. If a software upgrade is required, obtain and install the required software release.
5. Mount the Smart Card Reader to the MFD and connect the USB cable to one of the rear ports.
Refer to Connect the USB Smart Card Reader to the MFD.
6. Install the Smart Card software Feature Enablement Key. Refer to Enter the Smart Card En-
ablement Key.
7. Configure Smart Card Authentication, the optional NTP, and the optional Alternate Login.
Refer to Configuring the Smart Card.
8. Installany required certificatesandconfigure validation settings. Refer to Configure a Security
Certificate.
9. Configure the MFD LDAPsettings. Refer to ConfigureAcquiring Logged-In User's Email Address.
2-1Xerox
®
AltaLink
®
Series
Smart Card Installation and Configuration Guide

Xerox AltaLink C8030 Specifications

General

Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Display	10.1-inch color touchscreen
Functions	Print, copy, scan, fax, email
Memory	4 GB
Duplex Printing	Automatic
Print Speed	30 ppm
Print Resolution	1200 x 2400 dpi
Connectivity	Ethernet, USB
Hard Drive	250 GB
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria, Xerox Print Service Plug-in for Android
Dimensions	635 x 559 x 762 mm
