Xerox B215 Service Manual

July 2019
6-9
Xerox® B205/B215 Multifunction Printer Service Manual
Product Specifications
General Procedures / Information
Initial Release
Copy Resolution Tex t •ADF
Scan 600 x 600 dpi (Optical 600 x 300 dpi),
P
rinting: 600 x 600 dpi
•Platen
Scan: 600 x 600 dpi (Optical 600 x 600 dpi),
P
rinting: 600 x 600 dpi
Text/Photo •ADF
Scan 600 x 600 dpi (Optical 600 x 300 dpi),
P
rinting: 600 x 600 dpi
•Platen
Scan: 600 x 600 dpi (Optical 600 x 600 dpi),
P
rinting: 600 x 600 dpi
Photo •ADF
Scan 600 x 600 dpi (Optical 300 x 300 dpi),
P
rinting: 600 x 600 dpi
•Platen
Scan: 1200 x 1200 dpi (Optical 300 x 300 dpi),
P
rinting: 1200 x 1200 dpi
Original Type Factory Default Text/Photo
Max Original Size Document Glass A4
Document Feeder
(A
DF)
Legal (8.5 x 14 in.)
Basic Copy Multi Copy 1 to 99
Automatic Paper
S
election
No
Manual Paper
S
election
Ye s
Duplex Copy Ye s
Darkness Control 11 levels
Magnification Document ADF: 25% - 400%
Document Platen: 25% - 100%
Table 4 Scan Function Specifications
Item Specification B205 / B215
Scan Method Color CIS cpm
Compatibility TWAIN, WIA
Color Mode B/W / Greyscale / Color
Scan Speed Line art, Halftone
(
mono)
17 ipm @ 300 dpi
Gray (mono) 17 ipm @ 300 dpi
Color 6 ipm @ 300 dpi
Table 3 Copy Function Specifications
I
tem Specification B205 / B215
Resolution Optical 1200 x 1200 dpi
Enhanced 4800 x 4800 dpi
Halftone 256 levels
Scan Size Max. Document
Wi
dth
216 mm (8.5 in.)
Effective Scan
Wi
dth
208 mm (8.2 in.)
Max. Document
Lengt
h
ADF: 356 mm (14 in.)
Document Glass: 297 mm (11.7 in.)
Effective Scan
Lengt
h
ADF: 328 mm (13.7 in.)
Document Glass: 289 mm (11.4 in.)
Scan Depth Color 24 bits
Mono 1 bit for Line art and Halftone
8 Bits for Gray scale
ADF Capacity 40 sheets @ 80 gsm
Document size Width: 142 to 216 mm
Length: 148 to 356 mm
Table 5 Fax Function Specifications
Item Specification B205 / B215
Compatibility ITU-T G3, ECM
Communication System PSTN/PABX
Modem Speed 33.6 Kbps
TX Speed Approx. 3 sec (Mono/Standard/ECM-MMR, @
I
TU-T G3 No.1)
Compression MH/MR/MMR/JBIG/JPEG
Color Fax Yes (Tx only)
ECM Ye s
Resolution (mono) Standard 203 x 98 dpi
Fine 203 x 196 dpi
S Fine 300 x 300 dpi
Table 4 Scan Function Specifications
I
tem Specification B205 / B215

Xerox B215 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	14 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIFF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution (black)	1200 x 1200 ppi
Faxing	Mono faxing
Fax forwarding to	Fax, PC
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Digital sender	-
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Sustainability certificates	ENERGY STAR
Control type	Touch
Product color	Black, White
Display diagonal	3.5 \
Market positioning	Business
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	40 sheets
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Compatibility	Xerox B215
Internal memory	256 MB
Card reader integrated	No
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Power consumption (standby)	46 W
Power consumption (PowerSave)	2 W
Power consumption (average operating)	417 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	1500 pages
Recommended monthly print volume	3000 pages
Package weight	14000 g
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	460 mm
Width	490 mm
Height	480 mm
