Xerox DocuMate 152 User Manual

DocuMate 152 Scanner User’s Guide 79
Scanning
To Transfer Documents to a Server or Mapped Drive
When selecting the storage location for scanned documents, you
can select a local folder, or a folder on a server or mapped
drive.You select a mapped drive using the Browse button.
1. See “Scanning to Multiple Archive Folders” on page 75 or
“Transferring Scanned Documents to Storage” on page 74 for
the steps to select the Transfer to Storage options.
2. On either the One Touch 4.0 Link Properties window, or from
the Scan Configuration Properties window, click the Browse
button.
The Browse For Folder window opens.
3. Select a storage location on the mapped drive or server for the
scanned documents.
Servers and mapped drives are represented by an icon that
indicates its network connection.
Select a mapped drive or
server as indicated by the
icon.

Xerox DocuMate 152 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	65536
Input color depth	24 bit
Maximum scan size	216 x 356 mm
Optical scanning resolution	600 x 1200 DPI
Flatbed scan speed (b/w, A4)	0.25 sec/page
Scanner type	Sheet-fed scanner
Product color	Gray
Sensor type	CCD
Daily duty cycle (max)	30000 pages
ISO A-series sizes (A0...A9)	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum RAM	512 MB
Minimum storage drive space	350 MB
Power supply type	-
Power consumption (standby)	6 W
Power consumption (typical)	30 W
Operating temperature (T-T)	10 - 35 °C
Package width	251.459 mm
Package height	253.999 mm
Package weight	4808.1 g

Weight and Dimensions

Depth	160 mm
Width	309 mm
Height	141 mm
Weight	2700 g
