Xerox DocuMate 3460
User’s Guide
156
Replacing the Roller Assembly
After extended use, the feed roller may wear out. It is a user-replaceable part and can be
reordered.
Frequent paper jams are a symptom of a worn roller assembly. A worn roller can cause documents to
feed in skewed at an angle, or multiple pages to feed at the same time. A worn roller should be
replaced to avoid damage to the scanner’s internal parts. Before replacing the roller you should clean it
as excessive dust on the roller will make it appear worn and smooth. You cannot properly diagnose a
worn roller until you have cleaned it.
1. Press the ADF cover release on the top left of the scanner body to open the Automatic Document
Feeder cover.
2. Lower the door that holds the feed roller in place.
