Xerox Phaser 3052

June 2014
Xerox
®
Phaser
®
3052/3260 Printer Service Manual
BSDs
A B C D E F G H J
1
2
3
4
5
6
10.2 PRINT EXIT
7-9
PL 1.1
MAIN PWB
+3.3 VDC
DC COM
+3.3 VDC
2
1
+3.3 VDC
OUTPUT TRAY FULL
(L) +3.3 VDC
+3.3 VDC
DC COM
EXIT SENSOR
PAPER AT EXIT
SENSOR (L) +3.3 VDC
+3.3 VDC
DC COM
PL 4.1
+3.3 VDC
DC COM
PL 4.1
HVPS PWB
3
EXIT_S
-
CN2CN
-
-
OUTPUT TRAY FULL
SENSOR
PL 4.3
20
P30 J30
7
J100 P100
OUTPUT TRAY FULL
