4-20
Xerox® Phaser® 3052/3260 Service Manual
REP 1.11, REP 1.12
Repairs
a. Release the wire harness from the top of the LSU and disconnect the connectors (2)
at the LSU (Figure 1).
b. Remove the screws (3) (Figure 2).
Figure 2 LSU Removal (Top View)
Replacement
Install the components in the reverse of removal.
REP 1.12 Retard Roll
Parts List on PL 6.1
Removal
1. Remove the Paper Tray and any paper from the tray.
2. In the Paper Tray, pull down on the latches (2) to open the Retard Roll Cover (Figure 1).
Figure 1 Retard Roll Cover Latches
3. Rotate the Retard Roll Holder up and remove it from the Paper Tray (Figure 2).
Screws
Latches

Xerox Phaser 3052 Specifications

General

Print Technology	Laser
First Page Out Time	As fast as 8.5 seconds
Maximum Paper Size	8.5 x 14 in.
Connectivity	USB 2.0
Media Sizes Supported	Letter, Legal, Executive, Folio, Oficio, Statement
Print Languages	PCL6, PostScript 3
Operating System Compatibility	Windows, Mac, Linux
