Xerox® Phaser® 3020 Printer Service Manual
IQ7, IQ8
Image Quality
Figure 1 Uneven Density
IQ8 Background RAP
Uniform toner contamination appears in most or all non-image areas of the printed sheet (Fig-
ure 1).
Initial Actions
• Check that media type settings are correct.
• Check that the paper meets specifications. Refer to Section 6 for product specifications.
• Check the supplies life of the Print Cartridge, refer to GP 2 Machine Status and Reports.
Replace the Print Cartridge if it has reached end of life.
Procedure
• Switch off the power.
• Clean the contacts on the Print Cartridge and the LVPS / HVPS PWB.
• Switch on the power and make a test print.
The test print looks OK.
YN
Replace the LVPS / HVPS PWB; (REP 1.5), PL 3.1.
Go to SCP 04 Final Actions.
Figure 1 Background

Xerox Phaser 3052 Specifications

General

Print Technology	Laser
First Page Out Time	As fast as 8.5 seconds
Maximum Paper Size	8.5 x 14 in.
Connectivity	USB 2.0
Media Sizes Supported	Letter, Legal, Executive, Folio, Oficio, Statement
Print Languages	PCL6, PostScript 3
Operating System Compatibility	Windows, Mac, Linux
