Xerox Phaser 3117 Service Manual

ExplodedView Parts List
Draw# Location SEC.Code Description Qt'y SVC Remark
7.1-0 - Phaser 3117 SET - -
7.1-1 F2090 JC96-03349A ELA UNIT-FRAME_LOWER 1 SA
001N00465
7.1-2 T4062 JC97-02177A MEA UNIT-COVER MAIN 1 SA
7.1-2-1 Z5090 JC61-01155A GUIDE-M-STACKER_RX 1 SA
002N02426
7.1-2-2 Z5092 JC61-01156A GUIDE-M-SUB STACKER 1 SA
7.1-2-3 Z2168 JC63-00618A COVER-M_TOP 1 SNA
7.1-2-4 Z2198 JC63-00619A COVER-M-MAIN 1 SNA
7.1-2-5 D0027 JC63-00620A COVER-M-JAM 1 SA
7.1-2-6 K0045 JC64-00184A KEY-M-ONLINE 1 SNA
7.1-2-7 A1013 JC66-00816A LEVER-M-ACTUATOR JAM 1 SA
7.1-2-8 W3274 JC67-00079A LENS-M_LED 1 SNA
7.1-3 Z2409 JC97-02176A MEA UNIT-COVER FRONT 1 SA
7.1-3-1 Z2146 JC63-00616A COVER-M_FRONT(DEVE) 1 SNA
7.1-3-2 K3955 JC63-00617A TRAY-M-CASSETTE 1 SNA
7.1-3-3 E5013 JC63-00628A TRAY-M-EXTENSION LARGE 1 SNA
7.1-3-4 E5014 JC63-00629A TRAY-M-EXTENSION SMALL 1 SNA
7.1-4 L7012 JC59-00023A UNIT-LSU 1 SA
122N00243
7.1-5 S7009 JC63-00621A COVER-M-SMPS 1 SA
7.1-6 T2060 JC96-03352B ELA UNIT-DEVE INITIAL, 1 SNA
7.1-7 F4038 JC96-03401A ELA HOU-FUSER 220V 1 SA
126N00245
☞
7.1-7 F4038 JC96-03400A ELA HOU-FUSER 110V 1 SA
☞ AC 110V
7.1-8 E2108 JC63-00632A SHIELD-P-ENGINE 1 SNA
120N00480
7.1-9 L7002 JC39-00406A CBF HARNESS-LSU 1 SA
7.1-10 S7050 JC44-00081A SMPS-(V2C) 1 SA
☞
105N02062
7.1-10 S7050 JC44-00080A SMPS-(V1) 1 SA
☞ AC 110V
7.1-11 Z1024 JC92-01640A PBA MAIN-USB_ONLY 1 SA
7.1-12 M2053 JC39-00405A CBF HARNESS-MOTOR 1 SA
152N11623
7.1-13 H1098 JC39-00400A CBF HARNESS-HVPS 1 SA
7.1-14 H1247 JC39-00402A CBF HARNESS-SMPS 1 SA
152N11625
7.1-15 K3197 JC96-01672A ELA UNIT-TERMINAL TR L 5 SA
116N00244
7.1-15-1 Z4197 JC61-00031A SPRING ETC--HV LARGE 1 SA
009N01410
7.1-15-2 S4027 JC70-40912A ICT-SHAFT HV LARGE 1 SA
105N02068
7.1-16 S7027 JC44-00079A HVPS-SKYLARK 1 SA
7.1-17 D2132 JC63-00722A HEET-HVPS 1 SA
7.1-18 K3232 JC63-00631A GROUND-P-HVPS 2 SNA
7.1-19 K2903 3903-000085 CBF-POWER CORD, 110V 1 SA
105N02072
7.1-19 K2903 3903-000042 CBF-POWER CORD, 220V 1 SA
7.1-20 P5151 JC61-01170A PLATE-P-CHANNEL 1 SA
015N00557
▣ SA: Service Available, SNA: Service not Available
7.1 Main
< Service Parts List >
< 6 >
