Draw# Location SEC.Code Description Qt'y SVC Remark
▣ SA: Service Available, SNA: Service not Available
7.2-0 F2090 JC96-03349A ELA UNIT-FRAME_LOWER 1 SA 001N00466
7.2-1 B0080 JC61-01152A FRAME-M-BASE 1 SNA
7.2-2 K3602 JC97-02218A MEA UNIT-PLATE KNOCK_UP 1 SA
015N00560
7.2-2-1 K5002 JC61-01158A PLATE-M-KNOCK_UP 1 SA
015N00561
7.2-2-2 P2158 JC66-00720A SHAFT-P-CORE;ML-1750,SECC 1.6T,220,-,-,- 1 SNA
7.2-2-3 K5006 JC72-01004A PMO-IDLE KNOCK UP MP 2 SA
7.2-2-4 K5007 JC74-00011A MPR-PAD KNOCK UP MP 1 SNA
019N00835
7.2-3 Z4271 JC61-01258A SPRING ETC-TORSION DEVE_L 1 SA
009N01516
7.2-4 Z4272 JC61-01259A SPRING ETC-TORSION DEVE_R 1 SA
009N01517
7.2-5 D4030 JC96-03518A ELA UNIT-RX DRIVE 1 SA
126N00246
7.2-5-1 B4025 JC61-01153A BRACKET-P-GEAR 1 SNA
7.2-5-2 M2048 JC61-01154A BRACKET-P-MOTOR 1 SNA
7.2-5-3 G0383 JC66-00804A GEAR-RDCN 139/83 1 SA
7.2-5-4 P2119 JC31-00020D MOTOR BLOWER-STEP 7.5 1 SA
127N07405
7.2-5-5 K4023 JC72-00825A PMO-IMPELLER_DRV 1 SNA
7.2-6 B0101 JC97-02175A MEA UNIT-FRAME PAPER PATH 1 SA
7.2-7 K2015 JC70-00500A ADJUST-M-CASSETTE_R 1 SA
026N00764
7.2-8 K2014 JC70-00499A ADJUST-M-CASSETTE_L 1 SA
026N00765
7.2-9 G0369 JG66-40003A GEAR-PINION;SF4000,POM,WHT,M1,Z1 1 SA
007N01178
7.2-10 F1011 JC61-00836A FOOT-FRONT;ML-1750,NBR,D7,-,12,-,- 2 SA
7.2-11 G0381 JC66-00805A GEAR-RDCN 113/83 1 SA
7.2-12 D4047 JC66-00806A GEAR-OPC DR 76/38/29 1 SA
007N01372
7.2-13 F4086 JC66-00807A GEAR-FUSER DR 63/35 1 SA
007N01373
7.2-14 F6076 JC66-00808A GEAR-FEED DR 41 1 SA
007N01374
7.2-15 K3816 JC66-00822A LEVER-M-ACTUATOR_EMPTY 1 SA
120N00481
7.2-16 Z4274 JB61-00076A SPRING ETC-TORSION DOC (CC2-F);SCX-1110
F 1 SA 009N01513
7.2-17 D4053 JC63-00622A GROUND-P-OPC 1 SA
115N00857
7.2-18 D4084 6107-001240 SPRING-CS 2 SNA
009N01518
7.2-19 A0003 JC67-00110A CAP-M-MOTOR 1 SNA
7.2-20 B2030 JC61-00025A SPRING-CS-CHARGE APOLLO;SF-5100, 2 SNA
7.2 Frame Assembly
< 7 >
