Draw# Location SEC.Code Description Qt'y SVC Remark
▣ SA: Service Available, SNA: Service not Available
7.3-0 F4038 JC96-03401A ELA HOU-FUSER 220V 1 SA
☞
126N00245
7.3-0 F4038 JC96-03400A ELA HOU-FUSER 110V 1 SA
☞
7.3-1 F2122 JC61-01162A FRAME-P-FUSER 1 SNA
7.3-2 Z2149 JC63-00615A COVER-M_FUSER 1 SNA
7.3-3 H4027 JC61-01177A HOLDER-M-EXIT R 2 SA
019N00839
7.3-4 E4038 JC66-00810A GEAR-EXIT_DRV17 1 SNA
007N01377
7.3-5 H4026 JC61-01172A HOLDER-M-EXIT F/DOWN 3 SNA
7.3-6 D4085 6107-001168 SPRING-CS 2 SNA
7.3-7 P6004 JC66-10901A BEARING-PRESSURE/R;ML-165,PPS,5,-,14.8 2 SA 013N13843
7.3-8 K3960 JC61-00595A GUIDE-M-INPUT;ML-1400,PET+GF30%,-,-,-,BL 1 SNA
7.3-9 P6014 JC66-00600A ROLLER-PRESSURE 1 SA
022N01611
7.3-10 H2010 JC66-00601A ROLLER-HEAT 1 SA
022N01610
7.3-11 F4094 JC66-00564A GEAR-FUSER, Z37;ML-1710,HTN51G35HSL,0.8, 1 SA
007N01205
7.3-12 K2879 JC61-00589A BUSH-M-HR L;ML-1400,PPS,-,-,-,-,V0 1 SNA 016N00282
7.3-13 K2880 JC61-00590A BUSH-M-HR R;ML-1400,PPS(RBA313N, CONDU
C 1 SA 016N00262
7.3-14 K2297 4713-001202 LAMP-HALOGEN, 220V 1 SA
☞
122N00245
7.3-14 K2297 4713-001203 LAMP-HALOGEN, 110V 1 SA
☞
7.3-15 R1083 JC66-00824A ROLLER-M-EXIT MAIN 3 SNA
7.3-16 R1084 JC66-00830A ROLLER-M-EXIT FR 3 SNA
7.3-17 D4085 6107-001168 SPRING-CS 2 SNA
7.3-18 D4086 6107-001163 SPRING-CS;SUS304-WPB,-,PI0.4,D3.9,L13,-, 3 SA
009N01496
7.3-19 W3071 1404-001298 HERMISTOR-NTC;7KOHM,-,3370K,0.3MW/C,-,- 1 SA
130N01266
7.3-20 K4279 JC47-00005B THERMOSTAT-150 1 SA 130N01411
7.3-21 H1089 JC39-00404A CBF HARNESS-FUSER JOINT 1 SA
152N11628
7.3-22 H1085 JC39-00403A CBF HARNESS-FUSER(110V) 1 SA
152N11631
7.3-23 B2031 JC61-00064A SPRING-CLAW;ML-5200A,SUS 304 WPB 4 SNA
009N01380
7.3-24 H4031 JC61-00584A HOLDER-M-PLATE CLAW;ML-1400,PET+GF30%
, 4SA
7.3-25 H4032 JC61-00605A PLATE-P-CLAW;ML-1400,SUS304-CSP,0.1,-,-, 4 SNA
7.3-26 E4039 JC66-00801A GEAR-EXIT_DR38/25 1 SNA
7.3-27 S2004 6031-001051 WASHER-PLAIN;M4,ID4.1,OD7.0,T0.1 1 SNA
7.3-28 D4086 6107-001163 SPRING-CS;SUS304-WPB,-,PI0.4,D3.9,L13,-, 3 SA
7.3-29 Z2194 JC63-00637A COVER-M-FUSER-DUMMY 1 SNA
7.3-30 L1014 JC63-00639A COVER-M-LAMP-L 1 SNA
7.3-31 L1015 JC63-00638A COVER-M-LAMP-R 1 SNA
7.3-32 D4088 6044-000001 RING-CS;ID3,OD3,T0.25,BLACK,SUS304 1 SNA
7.3-33 E4159 JC66-00826A ROLLER-EXIT F/DOWN 1 SA
7.3-34 H4087 JC67-00085A CAP-M-THERMO 1 SNA
7.3 Fuser Unit
