Draw# Location SEC.Code Description Qt'y SVC Remark
▣ SA: Service Available, SNA: Service not Available
7.4-0 B0101 JC97-02175A MEA UNIT-FRAME PAPER PATH 1 SA
7.4-1 G2069 JC61-01161A GUIDE-M-PAPER PATH 1 SA
038N00463
7.4-2 E7006 JC66-00814A LEVER-ACTUATOR FEED SENSOR 1 SA
130N01408
7.4-3 Z4209 JB61-00107A 0PRING ETC-LEVER SENSOR;SF-430,SUS304,0 1 SA
009N01519
7.4-4 K3377 JC70-10232A IPR-PLATE SAW 1 SA
015N00558
7.4-5 W3076 JC63-00625A GROUND-P-VARISTOR 1 SNA
7.4-6 W3077 JC63-00624A GROUND-P-ZENER 1 SNA
7.4-7 W3078 JC63-00623A GROUND-P-THV 1 SNA
7.4-8 W3079 JC63-00626A GROUND-P-SAW 1 SNA
7.4-9 P0015 JC97-02217A MEA UNIT-HOLDER_PAD 1 SA
019N00841
7.4-9-1 Z4137 JC61-70911A SPRING ETC-EXIT ROLL FD;ML-165,SUS304 W
P 2SA
7.4-9-2 R1049 JC69-00846A PAD-FRICTION 1 SNA
019N00836
7.4-9-3 H4029 JC61-01169A HOLDER-M-PAD 1 SA
7.4-10 R1120 JC66-00814A LEVER-M-KICKER P/U 2 SNA
7.4-11 P2093 JC97-02179A MEA UNIT-PICK UP GEAR 1 SA
130N01419
7.4-11-1 P2056 JC66-00803A GEAR-PICK_UP B 1 SA
7.4-11-2 P2057 JC66-00802A GEAR-PICK_UP A 1 SA
7.4-11-3 D4089 6107-001167 SPRING-CS 1 SA
7.4-12 S8014 JC33-00015B SOLENOID-MP_R2;-,SCX-4720F,DC24V,-,-,-,- 1 SA
121N01078
7.4-13 F6071 JC66-00809A GEAR-FEED 35/19 1 SA
007N01375
7.4-14 K2886 JC61-00588A BUSH-M-TR L;ML-1400,POM(M90-44),-,-,-,BL 1 SA 016N00261
7.4-15 K3856 JC72-00102A PMO-BUSHING_TR(L);SF-5100,POM ,B 1 SA
016N00254
7.4-16 Z4277 JC61-70940A SPRING ETC-TR(12) 2 SNA
009N01521
7.4-17 T3014 JC66-00725A ROLLER-TRANSFER;SCX-4100,NBR FOAM,¾å
1 5A022N02126
7.4-18 H4041 JC61-00583A HOLDER-PTL;ML-1400,ABS,-,-,-,BLK,- 1 SA
019N00818
7.4-19 K3367 JC70-00307A IPR-P-EARTH TRANSFER;ML-1400,SECC,-,1.0T 1 SA
115N00854
7.4-20 P2160 JC66-00829A SHAFT-P-PICK_UP 1 SA
7.4-21 P2067 JC61-01151A HOUSING-M-PICK_U 1 SNA
7.4-22 P2068 JC61-01173A HOUSING-M-PICK_UP B 1 SNA
7.4-23 P2148 JC73-00211A RUBBER-PICK_UP 1 SA
130N01409
7.4-24 P2042 JC66-00811A CAM-M-PICK_UP 2 SA
130N01410
7.4-25 G0448 JC66-00813A GEAR-TRANSFER 1 SA
007N01376
7.4-26 - JC61-01281A BRACKET-P-BAR_PICK-UP; 1 SNA
7.4 Paper Path Assembly
< 9 >
