Xerox PHASER 3435 User Manual

2.7 < System setup>
Printing a demo page
Print a demo page to make sure that the printer is operating correctly.
1 Press Menu and then OK when Information appears.
2 Press the Up/down arrow buttons until Demo Page appears and
press OK.
A demo page prints out.
Changing the display language
To change the language that is displayed on the control panel, follow
these steps:
1 Press Menu until System Setup appears on the bottom line of the
display and press OK.
2 Press OK when Language appears.
3 Press the Up/down arrow buttons to select the language you want
and press OK.
4 Press Start/Stop to return to Standby mode.
Using toner save mode
Toner save mode allows the printer to use less toner on each page.
Activating this mode extends the life of your print cartridge and reduces
your cost per page beyond what one would experience in the normal
mode, but it reduces print quality.
There are two ways to enable this mode:
Using the control panel button
Press Toner Save on the control panel. The printer must be in Standby
mode; the Status LED lights green and Ready is shown on the display.
• If the button backlight is on, the mode is enabled and the printer uses
less toner to print a page.
• If the button backlight is off, the mode is disabled and the printer prints
in normal mode.
From the software application
You can set toner save mode from the printer properties window on your
printer driver. See the Software Section.

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
