Xerox PHASER 3435 User Manual

Using Utility Applications
24
6 Using Utility Applications
If an error occurs while printing, the Status Monitor window
appears, showing the error.
N OTES :
• To use the this program, you need:
- To check for Operating System(s) that are compatible with
your printer, refer to Printer Specifications in your Printer
User’s Guide.
- Internet Explorer version 5.0 or higher for flash animation
in HTML Help.
• If you need to know the exact name of your printer, you can
check the supplied CD-ROM.
Using Printer Settings Utility
Using the Printer Settings Utility, you can configure and check
print settings.
1 from the Start menu, select Programs or All Programs
→ your printer driver name → Printer Settings Utility .
2 Change the settings.
3 To send the changes to the printer, click the Apply button.
Using Onscreen Help
For more information about Printer Settings Utility , click .
Opening the Troubleshooting
Guide
Using the troubleshooting guide, you can view solutions for
error status problems.
Double click the Status Monitor icon on the Windows task bar.
Or, from the
Start menu, select Programs or All Programs
→ your printer driver name → Troubleshooting Guide .
Changing the Status Monitor
Program Settings
Select the Status Monitor icon on the Windows task bar and
right-click on the Status Monitor icon. Select
Options .
The following window opens.
• Display when job is finished for network printer shows
the Status Monitor balloon when your job is complete.
(Only for a network supported printer.)
• Display when error occurs during printing shows the
Status Monitor balloon when an error occurs during
printing.
• Schedule an automatic status checking every allows
the computer to update the printer status regularly.
Setting the value close to 1 second causes the computer
to check the printer status more frequently, thereby
allowing a faster response to any printer error.
Double click this icon.

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
