Xerox PHASER 3435 User Manual

5.8 < Loading print media>
Selecting an output location
The printer has two output locations; the rear cover (face up) and the
output tray (face down).
The printer sends output to the output tray by default. To use the output
tray, make sure that the rear cover is closed.
Notes
• If paper coming out of the output tray has problems, such as
excessive curl, try printing to the rear cover.
• To avoid paper jams, do not open or close the rear cover while
the printer is printing.
Printing to the output tray (Face down)
The output tray collects paper face down, in the order in which the sheets
were printed. The tray should be used for most print jobs.
1
1
rear cover
2
output tray
2
Printing to the rear cover (Face up)
Using the rear cover, paper comes out of the printer face up.
Printing from the multi-purpose tray to the rear cover provides a straight
paper path. Using the rear cover might improve the output quality with
special print media.
To use the rear cover, open it by pulling down.
Caution
The fuser area inside the rear cover of your printer becomes
very hot when in use. Take care when you access this area.

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
