Xerox PHASER 3435 User Manual

Using Your Printer with a Macintosh
31
9 Using Your Printer with a
Macintosh
Your printer supports Macintosh systems with a built-in USB
interface or 10/100 Base-TX network interface card. When you
print a file from a Macintosh computer, you can use the driver by
installing the PPD file.
This chapter includes:
• Installing printer driver for Macintosh
• Setting Up the Printer
•Printing
Installing printer driver for
Macintosh
The PostScript driver CD-ROM that came with your machine
provides you with the PPD file to use the PS driver, Apple
LaserWriter driver, for printing on a Macintosh computer.
1 Connect your machine to the computer using the USB
cable or the Ethernet cable.
2 Turn on your computer and the machine.
3 Insert the PostScript driver CD-ROM which came with your
machine into the CD-ROM drive.
4 Double-click CD-ROM icon that appears on your
Macintosh desktop.
5 Double-click the MAC_Installer folder.
6 Double-click the MAC_Printer folder.
7 For Mac OS 10.3 or higher, double-click the Xerox
Phaser 3435_OSX
icon.
8 Enter the password and click OK .
9 Click Continue .
10 Select Easy Install and click Install .
11 After the installation is finished, click Quit .
Uninstalling the printer driver
1 Connect your machine to the computer using the USB
cable or the Ethernet cable.
2 Turn on your computer and the machine.
3 Insert the PostScript driver CD-ROM which came with your
machine into the CD-ROM drive.
4 Double-click CD-ROM icon that appears on your
Macintosh desktop.
5 Double-click the MAC_Installer folder.
6 Double-click the MAC_Printer folder.
7 For Mac OS 10.3 or higher, double-click the Xerox
Phaser 3435_OSX
icon.
8 Select Uninstall and then click Uninstall .
9 Click Continue .
10 When the uninstallation is done, click Quit .

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
