8.4 < Maintenance>
3 Remove the new print cartridge from its bag.
Caution
Do not use sharp objects, such as a knife or scissors, to open
the print cartridge package. They might scratch the drum of
the cartridge.
4 Remove the packing tape and roll the cartridge 5 or 6 items to
distribute the toner.
Thoroughly roll the cartridge to assure maximum copies per
cartridge. Save the box and the plastic bag for shipping.
Cautions
• If toner gets on your clothing, wipe it off with a dry cloth and
wash clothing in cold water. Hot water sets toner into fabric.
• To prevent damage to the print cartridge, do not expose it to
light for more than a few minutes. Cover it with a piece of
paper, if necessary.
• Do not touch the green surface underside of the print
cartridge. Use the handle on the cartridge to avoid touching
this area.
5 Hold the print cartridge by the handle and slowly insert the cartridge
into the opening in the printer.
6 Tabs on the sides of the cartridge and corresponding grooves
within the printer will guide the cartridge into the correct position
until it locks into place completely.
7 Close the front cover. Make sure that the cover is securely closed.
Clearing the Toner Low Replace Toner message
When the Toner Low Replace Toner message appears you can
configure not to see this message again not to disturb you.
1 Press Menu until System Setup appears on the bottom line of the
display and press OK.
2 Press the scroll buttons until Maintenance appears and press OK.
3 Press the scroll buttons until CLR Empty MSG. appears and press
OK.
4 Select On and press OK.
5 Now the Toner Low Replace Toner message does not appear but
the Replace Toner message will remain for reminding you that the
new cartridge needs to be installed for quality.
Caution
Once you have selected On, this setting will be permanently
written to the memory of the print cartridge, and this menu will
be disappeared from the Maintenance menu.
Maintenance parts
To avoid print quality and paper feed problems resulting from worn parts
and to maintain your printer in top working condition the following items
will need to be replaced at the specified number of pages or when the
life span of each item has expired.
Xerox highly recommends that an authorized service provider, dealer or
the retailer where you bought printer performs this maintenance activity.
The warranty does not cover the replacement of the maintenance parts
after their lifespan.
Items Yield (Average)
Transfer roller 70,000 page
Pick-up roller 150,000 page
Fuser unit 80,000 page

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
