Using the Hole Puncher
Phaser® 5550 Printer
4-54
Using the Hole Puncher
Depending on your region, the optional finisher is factory configured with either a 3-hole
punch or a 2- / 4-hole punch unit. To determine which option is installed on your printer, print
a Configuration Page from the control panel.
■ When the hole punch option is turned on, sheets that are sent to the Stacker Upper Tray or
the Stacker Lower Tray are punched.
■ When the hole punch option is turned off, no paper is punched.
■ When the printer detects that the punch waste box is full, a warning appears on the control
panel, and printing continues without punching.
To select hole punching in a supported driver:
Setting the Default Hole Punching Option
The default hole punching option is selected through the control panel or through
CentreWare IS.
Control Panel
To set the default hole punching option on the control panel:
1. On the control panel, select
Printer Setup, and then press the OK button.
2. Select
Paper Handling Setup, and then press the OK button.
3. Select
Punch, and then press the OK button to toggle it on or off.
4. If you have a 2-hole and 4-hole punch, then set
Punch Holes to 2 Holes or 4 Holes.
CentreWare IS
1. Launch your web browser.
2. Enter your printer’s IP address in the browser’s Address field.
3. Click Properties.
4. In the left navigation tree, expand General and then click Printer Defaults.
5. Select On or Off in the Punch drop-down menu.
6. Select the desired number of holes in the Punch Holes drop-down menu.
7. Click the Save Changes button.
Operating System Steps
Windows 2000 or later 1. Select the Paper Output tab.
2. Select Hole Punch or the number of holes in the Hole Punch
drop-down list.
Mac OS X (version 10.3
and higher) driver
1. In the Print dialog box, select Finishing Options from the
drop-down list.
2. Select the number of holes under Hole Punching.

Xerox Phaser 5550 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Warm-up time (from sleep mode)	37 s
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Storage media	HDD
Internal memory	256 MB
Maximum internal memory	1024 MB
Internal storage capacity	40 GB
Sound power level (standby)	5 dB
Sound pressure level (printing)	7.19 dB
Total input capacity	1100 sheets
Maximum input capacity	4100 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, PrintingScout Alert Notification, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	833.11 mm
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX Ethernet
Wireless technology	IEEE802.11a/b/g
Storage temperature (T-T)	41 - 90 °F
Power consumption (active)	900 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X 10.2, Novell NetWare 4.x, Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista, Xerox Walk-Up PD
Duty cycle letter size (maximum)	300000 pages per month
Acoustic power emissions (standby)	50 dB
Standard output capacity for envelopes	500 sheets
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	71.9 dB
PCL fonts	83
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Country of origin	China
Maximum duty cycle	50000 pages per month
Number of PostScript fonts	139
Sustainability certificates	ENERGY STAR
Power consumption (standby)	11 W
Power consumption (PowerSave)	105 W
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Height	749.29 mm
Package weight	65772 g
Dimensions (WxDxH)	1380 x 650 x 1050 mm
