Xerox PrimeLink B9110 User Manual

7. Move lever 33bb on the right of the fuser unit as necessary, then remove the jammed paper.
If the jammed paper remains inside and it is difficult to remove, return the transfer module to the original
position, then pull out the duplex module. Try again to remove the jammed paper.
8. Lower the handle under the center of the transfer module, then remove the jammed paper.
9. Insert the transfer module completely, then rotate the green lever 22 to the left.
Note: If the lever cannot be turned, pull out the transfer module to the middle, then insert it again.
10. Close the front cover completely. If the front cover is open even slightly, the printer does not operate.
244
Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136 Copier/Printer User Guide
Troubleshooting

Xerox PrimeLink B9110 Specifications

General

Brand	Xerox
Model	PrimeLink B9110
Category	Printer
Language	English
