5. Return lever 11cc to the original position.
6. Close the inserter front cover.
Clearing Paper Jams from the Inserter E3 Area
1. Open the inserter front cover.
2. To remove paper jams from the inserter E3 area:
Note: The jammed paper can be hidden behind the upper-left cover area.
a. Push down lever 11dd.
b. Rotate knob 11ee counterclockwise.
