a. Lift lever 11dd.
b. Remove the jammed paper.
Note: If paper is torn, check inside the printer, then remove the torn paper.
3. If the jammed paper cannot be removed, do the following steps:
a. Rotate knob 11cc clockwise.
b. Remove the jammed paper.
4. Return lever 11dd to the original position.
5. Close the front cover of the OHCF.
Note: If the front cover of the OHCF is not closed completely, a message appears on the printer touch
screen, and the printer cannot operate.
Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136 Copier/Printer User Guide 325
Oversized High Capacity Feeder
