Xerox VersaLink B605 User Manual

Fax
FFaaxx OOvveerrvviieeww
When you send a fax from the printer control panel, the document is scanned
and transmitted to a fax machine, using a dedicated telephone line. You can
use the Fax feature to fax documents to a fax number, or individual contact, or
to a group of contacts.
You can use the Fax feature to do the following tasks:
• Delay the send of your fax job for up to 24 hours.
• Send a fax from your computer.
• Forward fax documents to an email address.
• Print a fax from a secure folder.
The fax function works best with an analog phone line. Voice-Over-Internet Protocols (VOIPs) such as
FIOS and DSL are not supported. Before you use the fax, configure the Fax Settings to ensure that the
settings are compatible with your local connection and regulations. The Fax Settings include optional
features that you can use to configure the printer for faxing.
Note: Not all options listed are supported on all printers. Some options apply only to a specific
printer model, configuration, operating system, or print driver type.
For details, refer to the System Administrator Guide at www.xerox.com/office/VLB605_VLB615docs.
You can adjust various settings for individual Fax jobs and save settings as Presets for future jobs. The
list of features can be customized, and some features could be hidden from view when the app is
installed. To view all available features and to find out more about customizing the Fax App, refer to
Customize and Personalize.
For information about all the app features and available settings, refer to Apps Features.
SSeennddiinngg aa FFaaxx
To send a fax:
1. At the printer control panel, press the Home button.
2. To clear previous App settings, touch Reset.
3. Load your original documents.
Xerox
®
VersaLink
®
B605/B615 Multifunction Printer
User Guide
111
Xerox
®
Apps

Xerox VersaLink B605 Specifications

General

Copier resize	25 - 400 %
Package depth	660 mm
Package width	600 mm
Package height	1000 mm
Package weight	41000 g
Country of origin	Vietnam
Maximum resolution	1200 x 1200 DPI
Optional connectivity	Wireless LAN
Maximum number of copies	999 copies
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Copy speed (black, normal quality, A4)	55 cpm
Book copy function	Yes
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	5.2 s
N-up printing	16
Print technology	Laser
Warm-up time (from sleep mode)	11 s
Time to first page (black, normal)	4 s
Print speed (black, normal quality, A4/US Letter)	55.5 ppm
Duplex print speed (black, normal quality, A4/US Letter)	49.3 ppm
PCL fonts	83
Digital sender	-
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3
Storage relative humidity (H-H)	10 - 95 %
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Scan speed (black)	58 ppm
Scan speed (color)	55 ppm
Output grayscale depth	8 bit
Image formats supported	JPG, TIF, TIFF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail, Fax
Control type	Touch
Product color	Blue, White
Market positioning	Business
Browser supported	Microsoft Internet Explorer, Microsoft Edge, Mozilla, Firefox, Apple Safari, Google Chrome
Printer management	DHCP, SNMP, WINS, HTTP, HTTPS, TLS, SNTP, MDNS
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, IPPS, IPSec, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Dropbox, Google Drive, OneDrive
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	TCP/IP:HTTP/HTTPS, InternetPrintingProtocol, LPR/LPD, RawSocketPrinting/Port9100, IPv4/IPv6, WSD, LDAP, Bonjour/AirPrint, FTP
Supported network protocols (IPv6)	IPv6
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	400 sheets
Total number of input trays	2
Custom media width	76 - 216 mm
Custom media length	127 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 128 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Compatibility	VersaLink B605/B615
Internal memory	4096 MB
Processor family	ARM
Processor frequency	1050 MHz
Card reader integrated	No
Internal storage capacity	250 GB
Sound power level (standby)	22.9 dB
Sound pressure level (printing)	58.3 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (sleep)	1.1 W
Power consumption (standby)	90 W
Power consumption (average operating)	820 W
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Other operating systems supported	HP-UX 11.31, IBM AIX 7.2, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	Phone
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	502.8 mm
Width	470 mm
Height	843.7 mm
Weight	39300 g
