Xerox VersaLink B605 - Internal Parts; Rear View

IInntteerrnnaall PPaarrttss
1. Front Door
2. Toner Cartridge
3. Drum Cartridge
4. Document Glass
5. Document Cover
RReeaarr VViieeww
1. Transfer Roller
2. Fuser
3. Rear Door
4. Wireless Network Adapter Port Cover
5. Phone Connector
6. Fax Line Connector
7. USB Port, Type A
8. USB Port, Type B
9. Ethernet Connection
10. FDI Port
11. Left-Side Panel, Access to optional
Productivity Kit
12. Power Connector
24
Xerox
®
VersaLink
®
B605/B615 Multifunction Printer
User Guide
Getting Started
