Xerox VersaLink B605 User Manual

• Touch the name of the network, enter the password for the selected network, then touch OK.
• If the desired network does not appear, touch Manual Setup, then configure the wireless
network settings.
– For Enter the Network Name (SSID), type the name (SSID) of your network, then press OK.
– Touch Security, then select the security method that your wireless network uses.
– Touch Enter Password, then enter the password for your wireless network.
– Touch OK.
5. To activate your Wi-Fi setting changes, press the Home button.
6. At the prompt, touch Restart Now.
7. After the printer restarts, wait two minutes, then to get the network information that includes the
IP address, print a Configuration Report. For more information, refer to Printing the Configuration
Report.
CCoonnnneeccttiinngg ttoo WWii--FFii DDiirreecctt
You can connect to your printer from a Wi-Fi mobile device, such as a tablet, computer, or
smartphone, using Wi-Fi Direct. Wi-Fi Direct is disabled by default.
Note: Wireless networking is available only on printers with the optional Wireless Network
Adapter installed.
Connecting with Wi-Fi Direct from Your Mobile Device
To connect with Wi-Fi Direct, follow the directions provided with your mobile device.
CCoonnnneeccttiinngg ttoo aa TTeelleepphhoonnee LLiinnee
WARNING: To reduce the risk of fire, use only No. 26 American Wire Gauge (AWG) or larger
telecommunication line cord.
1. Ensure that the printer is powered off.
2. Connect a standard RJ11 cable, No. 26 American Wire Gauge (AWG) or larger, to the Line port on
the back of the printer.
3. Connect the other end of the RJ11 cable to an operating telephone line.
4. Power on the printer.
5. Enable and configure the Fax functions.
IInniittiiaall PPrriinntteerr SSeettuupp
Before installing the printer software, verify that the printer is set up correctly. Setup includes
enabling the optional features and assigning an IP address for the Ethernet network connection. The
installation wizard starts automatically the first time the printer is powered on. The installation wizard
prompts the system administrator to configure the following settings:
Xerox
®
VersaLink
®
B605/B615 Multifunction Printer
User Guide
47
Getting Started

Xerox VersaLink B605 Specifications

General

Copier resize	25 - 400 %
Package depth	660 mm
Package width	600 mm
Package height	1000 mm
Package weight	41000 g
Country of origin	Vietnam
Maximum resolution	1200 x 1200 DPI
Optional connectivity	Wireless LAN
Maximum number of copies	999 copies
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Copy speed (black, normal quality, A4)	55 cpm
Book copy function	Yes
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	5.2 s
N-up printing	16
Print technology	Laser
Warm-up time (from sleep mode)	11 s
Time to first page (black, normal)	4 s
Print speed (black, normal quality, A4/US Letter)	55.5 ppm
Duplex print speed (black, normal quality, A4/US Letter)	49.3 ppm
PCL fonts	83
Digital sender	-
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	0 - 25000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3
Storage relative humidity (H-H)	10 - 95 %
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Scan speed (black)	58 ppm
Scan speed (color)	55 ppm
Output grayscale depth	8 bit
Image formats supported	JPG, TIF, TIFF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail, Fax
Control type	Touch
Product color	Blue, White
Market positioning	Business
Browser supported	Microsoft Internet Explorer, Microsoft Edge, Mozilla, Firefox, Apple Safari, Google Chrome
Printer management	DHCP, SNMP, WINS, HTTP, HTTPS, TLS, SNTP, MDNS
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, IPPS, IPSec, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Dropbox, Google Drive, OneDrive
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	TCP/IP:HTTP/HTTPS, InternetPrintingProtocol, LPR/LPD, RawSocketPrinting/Port9100, IPv4/IPv6, WSD, LDAP, Bonjour/AirPrint, FTP
Supported network protocols (IPv6)	IPv6
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	400 sheets
Total number of input trays	2
Custom media width	76 - 216 mm
Custom media length	127 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 128 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Compatibility	VersaLink B605/B615
Internal memory	4096 MB
Processor family	ARM
Processor frequency	1050 MHz
Card reader integrated	No
Internal storage capacity	250 GB
Sound power level (standby)	22.9 dB
Sound pressure level (printing)	58.3 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (sleep)	1.1 W
Power consumption (standby)	90 W
Power consumption (average operating)	820 W
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Other operating systems supported	HP-UX 11.31, IBM AIX 7.2, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	Phone
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	502.8 mm
Width	470 mm
Height	843.7 mm
Weight	39300 g
