Xerox VersaLink B7130 User Manual

Note: For Macintosh, to print portrait text and images in landscape orientation, clear the Auto Rotate
check box.
ADVANCED TAB
You can use the Advanced tab to set advanced printing options. Selections on this tab apply to all jobs that you
print with the print driver.
Note: Not all options listed are supported on all printers. Some options apply only to a specific printer model,
configuration, operating system, or print driver type.
Job Identification
You can use the Job ID feature to change the job identification setting for your print job. You can print the job
identification on a separate banner page or on the pages of your document.
The following options are available:
• DDiissaabbllee JJoobb IIDD: This option directs the printer not to print a banner page.
• PPrriinntt IIDD oonn aa BBaannnneerr PPaaggee: This option prints the job identification on a banner page.
• PPrriinntt IIDD iinn MMaarrggiinnss -- FFiirrsstt PPaaggee OOnnllyy: This option prints the job identification on the first page of the
document in the top-left margin.
• PPrriinntt IIDD iinn MMaarrggiinnss -- AAllll PPaaggeess: This option prints the job identification in the top-left margin on every page of
the document.
Printing Mirror Images
If the PostScript driver is installed, you can print pages as a mirror image. Images mirror left to right when printed.
Selecting Job Completion Notification for Windows
You can select to be notified when your job finishes printing. A message appears on your computer screen with the
name of the job and the name of the printer where it was printed.
Note: This feature is only available on a Windows computer printing to a network printer.
To select job completion notification from the Advanced tab:
1. Click NNoottiiffiiccaattiioonnss.
2. Click NNoottiiffyy ffoorr CCoommpplleetteedd JJoobbss, then select an option.
• EEnnaabblleedd: This option turns on notifications.
• DDiissaabblleedd: This option turns off the Notification feature.
3. Click OOKK.
152
Xerox
®
VersaLink
®
B71XX Series Multifunction Printer User Guide
Printing

Xerox VersaLink B7130 Specifications

General

N-up printing	16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.2 s
Print speed (black, normal quality, A3)	17 ppm
Duplex print speed (ISO/IEC 24734, A3) black	11 ppm
Print speed (black, normal quality, A4/US Letter)	30 ppm
Optional connectivity	Wireless LAN
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	@PrintByXerox, Apple AirPrint, Mopria Print Service
Processor cores	2
Internal storage capacity	320 GB
Sound power level (standby)	4.1 dB
Sound power level (printing)	6.8 dB
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	4.3 s
Copy speed (black, normal quality, A4)	30 cpm
Display	LCD
Control type	Touch
Product color	Blue, White
Display diagonal	7 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	480 W
Power consumption (sleep)	0.4 W
Power consumption (standby)	94 W
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supported	HP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Scan to	E-mail, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 431.8 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPG, TIFF
Document formats supported	PDF
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Faxing	-
PCL fonts	83
Printer fonts	PCL, PostScript
Printing colors	Black
Duplex functions	Copy, Print, Scan
Maximum duty cycle	129000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Page description languages	HP-GL, JPEG, PCL 5, PCL 6, TIFF, XPS
Total input capacity	620 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	520 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	130 sheets
Custom media width	139.7 - 297 mm
Custom media length	182 - 431.8 mm
Duplex media weight	60 - 169 g/m²
Paper tray media types	Bond paper, Card stock, Glossy paper, Heavy paper, Heavy printing media, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5
Multi-purpose tray media types	Bond paper, Envelopes, Glossy paper, Heavyweight paper, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 216 g/m²
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Current rating	12 A
Browser supported	Microsoft, Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages support	Multi
Supported network protocols	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour/AirPrint FTP

Weight and Dimensions

Depth	670.8 mm
Width	615.7 mm
Height	766.5 mm
