Xerox VersaLink B7130 User Manual

PRINTING ON CUSTOM-SIZE PAPER
Note: Before you print on custom-size paper, define the custom width and length of the paper in the print
driver software and on the printer control panel. For more information, refer to Defining a Custom Paper Size
at the Control Panel.
Printing on Custom-Size Paper from the Windows V3 Print Driver
Note: Before you print on custom-size paper, define the custom size in the Printer Properties. For details, refer
to Creating and Saving Custom Sizes for the Windows V3 Print Driver.
1. Load the custom-size paper in the tray.
2. In the application, click FFiillee >> PPrriinntt, then select your printer.
3. In the Print dialog box, click PPrriinntteerr PPrrooppeerrttiieess.
4. On the Printing Options tab, from the Paper list, select the required custom paper size and type.
5. Select any other required options, then click OOKK.
6. In the Print dialog box, click PPrriinntt.
Printing on Custom-Size Paper from the Windows V4 Print Driver
Note: Before you print on custom-size paper, define and save the custom paper size as a Form. For details,
refer to Printing on Custom-Size Paper from the Windows V4 Print Driver.
1. Load the custom-size paper in the tray.
2. In the application, click FFiillee >> PPrriinntt, then select your printer.
3. In the Print dialog box, click PPrriinntteerr PPrrooppeerrttiieess.
4. On the Printing Options tab, from the Paper list, select OOtthheerr SSiizzee.
5. To select a custom paper size, select FFiitt ttoo NNeeww PPaappeerr SSiizzee, then select the custom paper size.
6. Select any other required options, then click OOKK.
7. In the Print dialog box, click PPrriinntt.
Printing on Custom-Size Paper from Macintosh
1. Load the custom-size paper. For details, refer to Loading Paper.
2. In the application, click FFiillee >> PPrriinntt.
3. From the Paper Size list, select the custom paper size.
4. Click PPrriinntt.
Xerox
®
VersaLink
®
B71XX Series Multifunction Printer User Guide 155
Printing

Xerox VersaLink B7130 Specifications

General

N-up printing	16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.2 s
Print speed (black, normal quality, A3)	17 ppm
Duplex print speed (ISO/IEC 24734, A3) black	11 ppm
Print speed (black, normal quality, A4/US Letter)	30 ppm
Optional connectivity	Wireless LAN
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	@PrintByXerox, Apple AirPrint, Mopria Print Service
Processor cores	2
Internal storage capacity	320 GB
Sound power level (standby)	4.1 dB
Sound power level (printing)	6.8 dB
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	4.3 s
Copy speed (black, normal quality, A4)	30 cpm
Display	LCD
Control type	Touch
Product color	Blue, White
Display diagonal	7 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	480 W
Power consumption (sleep)	0.4 W
Power consumption (standby)	94 W
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supported	HP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Scan to	E-mail, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 431.8 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPG, TIFF
Document formats supported	PDF
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Faxing	-
PCL fonts	83
Printer fonts	PCL, PostScript
Printing colors	Black
Duplex functions	Copy, Print, Scan
Maximum duty cycle	129000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Page description languages	HP-GL, JPEG, PCL 5, PCL 6, TIFF, XPS
Total input capacity	620 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	520 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	130 sheets
Custom media width	139.7 - 297 mm
Custom media length	182 - 431.8 mm
Duplex media weight	60 - 169 g/m²
Paper tray media types	Bond paper, Card stock, Glossy paper, Heavy paper, Heavy printing media, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5
Multi-purpose tray media types	Bond paper, Envelopes, Glossy paper, Heavyweight paper, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 216 g/m²
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Current rating	12 A
Browser supported	Microsoft, Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages support	Multi
Supported network protocols	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour/AirPrint FTP

Weight and Dimensions

Depth	670.8 mm
Width	615.7 mm
Height	766.5 mm
