Versant 80 Press
Customer Expectation & Installation Guide
Module Name Width
Depth
Height Weight
BR Booklet Finisher 21.5 in / 542 mm
25 in / 635 mm
39.5 in / 1002 mm 133 lb / 60 kg
Interface Module
NOTE: The Interface Module is required with
any system con- figuration that has one or
more finishing device, except the OCT
13.5 in / 323 mm
28.5 in / 724 mm
39 in / 990.6mm 110 lb / 50 kg
GBC AdvancedPunch Pro 17.5 in. / 445 mm
28.5 in
/ 724 mm
38.5 in
/ 978 mm 220 lbs / 100 kg
High Capacity Stacker (HCS) 31.5 in / 800 mm
28.5 in
/ 724 mm
41 in
/ 1041 mm 251 lb
/ 114 kg
Standard Finisher without optional C/Z
Folder
41.1 in / 1044 mm
28.6 in
/ 726.4 mm
45.9 in
/ 1165.8 mm 289 lb
/ 131 kg
S
andard
Finisher
with optional C/Z Folder 49 in / 1244.6mm
28.6 in
/ 726.4 mm
45.9 in
/ 1165.8 mm 319 lb
/ 144.7 kg
Booklet
Maker
Finisher without optional C/Z
Folder
41.3 in / 1049 mm
28.6 in
/ 726.4 mm
45.9 in
/ 1165.8 mm 289 lb
/ 131 kg
Booklet Maker Finisher with optional C/Z
Folder
49.2 in / 1249.7mm
28.6 in
/ 726.4 mm
45.9 in
/ 1165.8 mm 386 lb
/ 175 kg
SquareFold Trimmer Module 50 in / 1270 mm
28.5 in
/ 724 mm
21.7 in
/ 551.2 mm 209 lb
/ 95 kg
2-Knife Trimmer Module 59 in / 1500 mm
27.6 in / 700 mm
47.2 in / 1200 mm 518 lb / 235 kg
The Standard Finisher Plus is comprised of the Finisher Module and the Finishing Transport.
Module Name Width
Depth
Height Weight
Standard Finisher Plus 72.6 in
/ 1844 mm
28.6 in
/ 726.4 mm
45.9 in
/ 1165.8mm 373.2 lb
/ 169.3 kg
Finisher Module (with optional C/Z Folder) 41.1 in
/ 1044 mm
28.6 in
/ 726.4 mm
45.9 in
/ 1165.8 mm 231 lb
/ 105 kg
Finishing Transport 31.5 in
/ 800 mm
25 in
/ 635 mm
39.5 in
/ 1003.3 mm 142.2 lb
/ 64.5 kg
Dimensions and Weights for the FreeFlow Server
Module Name Width
Depth
Height Weight
ontroller 6.9 in / 175 mm
16.4 in / 471 mm
14.2 in / 360 mm 20.68 lb / 9.4 kg
Monitor (19in)
Keyboard 18.5 in / 469.9 mm
6.75 in / 171.45 mm
2 in / 55 mm
Optional stand 28.25 in / 718 mm
24.75 in / 629 mm
37.5 in / 946 mm
Print Server Cables (common for print servers)
Item Length
Communications cables (connecting the print server with the press)
14.8 feet / 4.5 meters
Image cables (connecting the print server with the press)
19.69 feet/6 meters
Module Dimensions for Optional Third Party Finishing Devices
NOTE: Always refer to the Finishing Solutions Planning Guide for the most up-to-date information on the optional, third-party
finishing devices. The latest information can be found at: http://xww.thefic.xerox.com/View/Collection-113169
Space Requirements / Service Space Envelope
Movable Configuration
Moveable installations can be used when the press is installed on a hard surface (concrete, wood, and/or with mobility plates).
The following press configurations are can be moved by one person, and is therefore considered moveable:
MSI+press+OCT
HCF+Press+OCT
OHCF+Press+OCT
Advanced HCF+Press+OCT
