Versant 80 Press
Customer Expectation & Installation Guide 45
Item 1-Tray OHCF / Advanced HCF
Current/run power 3 amps/65 watts
Voltage (VAC) 1-Tray OHCF
–
100-120V 2.5A, 220-240V 1.5A
Advanced HCF – 100-120V 5A, 220-240V 3A
Power cord
length
8.2 feet/2.5 meters
Receptacle NEMA part number
5-15R or 5-20R
NOTE: Use surge protection only as required, and it is the responsibility of the customer.
Optional finishing device Current / run power Voltage (VAC) Power cord length Receptacle NEMA
part number
1-Tray OHCF 2.5 amps
1.5 amps
100-120
220-240
8.2 feet / 2.5 meters 5-15R or 5-20R
Advanced HCF (Single or Dual
configuration)
5 amps
3 amps
100-120
220-240
8.2 feet / 2.5 meters 5-15R or 5-20R
Interface Module 1.5 amps 100-240 8.2 feet / 2.5 meters 5-15R
GBC AdvancedPunch Pro 1.2 amps 100-240 8.2 feet / 2.5 meters 5-15R
High Capacity Stacker (HCS) 0.8 amps 100-240 8.2 feet / 2.5 meters 5-15R
Standard Finisher 2 amps 100-240 8.2 feet / 2.5 meters 5-15R
Booklet Maker Finisher 2 amps 100-240 8.2 feet / 2.5 meters 5-15R
SquareFold Trimmer Module 0.4 amps 100-240 8.2 feet / 2.5 meters 5-15R
2-Knife Trimmer Module 4 amps 100-230 14.8 feet / 4.5 meters 5-15R
Standard
Finisher Plus
Finisher
Module
1 amps 100-240 8.2 feet / 2.5 meters 5-15R
Finisher
Transport
5 amps 100-240 8.2 feet / 2.5 meters 5-15R
NOTE: The Standard Finisher Plus requires two NEMA receptacles (NEMA 5-15R or 5-20R).
Electrical Requirements for the Print Servers
FreeFlow Print Server
Print Server Item Current / run power Voltage (VAC),
North America
(NA)
Power cord length Receptacle NEMA
part number
Monitor 25 watts 100-240v
50/60 Hz +/- 3 Hz
7.5 feet/2.3 meters 5-15R
Controller (hard drive)
365 Watts
5.5 amps at 110 VAC and 2.5 amps
at 20 VAC
100-240 V
50 / 60 Hz
7.5 feet/2.3 meters 5-15R
