Xerox WorkCentre 3045 User Manual

Features
WorkCentre 3045 Multifunction Printer 23
User Guide
Symbol Name Description
Fax
Available on
WorkCentre 3045NI
Multifunction Printer
only.
Allows you to change job settings for fax jobs.
Job Status Displays active jobs.
System Displays or closes the System Menu screen.
Address Book
Available on
WorkCentre 3045NI
Multifunction Printer
only.
Allows you to access the printer address book.
Forward Arrow Moves one level down in menu selections or moves the cursor to the
right when setting a value.
Back Arrow Moves one level up in menu selections or moves the cursor to the left
when setting a value.
Up Arrow Displays the previous menu or item.
Down Arrow Displays the next menu or item.
OK Selects or executes the option or function displayed on the screen.
Return Navigates up one menu level.
Power Saver Indicates the Energy Saver status. Controls exit from Energy Saver
Mode.
Stop Stops the current operation.
Clear All Clears the current settings for print, copy, scan, or fax job to the
default settings.

Xerox WorkCentre 3045 Specifications

General

Duplex printing	No
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
All-in-one functions	Copy, Fax, Print, Scan
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows Server 2003\\r Windows Server 2008\\r Windows 7\\r Mac OS v10.5+
Printing colors	Black
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	24 s
Scan to	E-mail, FTP, USB
Output color depth	8 bit
Image formats supported	JPG, TIF
Document formats supported	PDF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Auto-redialing	Yes
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	99
Paper input type	Paper tray
Total input capacity	150 sheets
Total output capacity	100 sheets
Maximum input capacity	175 sheets
Multi-Purpose tray input capacity	10 sheets
Auto document feeder (ADF) input capacity	15 sheets
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
Auto Document Feeder (ADF) media weight	60 - 105 g/m²
Display	LCD
Market positioning	Home & office
Standard interfaces	USB 2.0
Internal memory	128 MB
Sound power level (standby)	15 dB
Sound pressure level (printing)	54 dB
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (off)	2.8 W
Power consumption (standby)	51.4 W
Power consumption (average operating)	332 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Sustainability certificates	ENERGY STAR
Certification	TUV, UL/CSA, CB/IEC, FCC

Weight and Dimensions

Depth	389 mm
Width	410 mm
Height	318 mm
