Troubleshooting
WorkCentre 7755/7765/7775 Multifunction Printer
User Guide
216
3. Grip the staple cartridge by the orange handle and remove it by pulling it firmly toward you. Check
inside the finisher for any loose staples and remove them.
4. Open the staple cartridge clamp by pulling firmly in the direction shown.
5. Remove the jammed staples (1), then push the clamp in the direction shown until it snaps into the
locked position (2).
Warning: The points of the jammed staples are sharp. Remove the jammed staples carefully.
wc77xx-100
