Troubleshooting
WorkCentre 7755/7765/7775 Multifunction Printer
User Guide
220
Clearing Booklet Staple Jams in the Professional Finisher and the Light
Production Finisher
The booklet stapler uses two staple cartridges labeled R2 and R3. Booklet stapling requires that both
staple cartridges be free of jammed staples.
Warning: Do not perform this procedure when the printer is copying or printing.
1. Open the finisher door.
2. While squeezing orange levers R2 and R3 together (1), pull the staple cartridge unit out of the
finisher until it stops (2).
Note: The staple cartridge unit does not detach from the finisher.
wc77xx-104
