KCU105 Board User Guide www.xilinx.com 9
UG917 (v1.4) September 25, 2015
Chapter 1: KCU105 Evaluation Board Features
Feature Descriptions
Figure 1-2 shows the KCU105 board. Each numbered feature that is referenced in Figure 1-2
is described in Table 1- 1 with a link to detailed information provided under Feature
Descriptions.
IMPORTANT: Figure 1-2 is for visual reference only and might not reflect the current revision of the
board.
CAUTION! The KCU105 board can be damaged by electrostatic discharge (ESD). Follow standard ESD
prevention measures when handling the board.
X-Ref Target - Figure 1-2
Figure 1-2: KCU105 Evaluation Board Components
3RZHU
/1.
7;
3&,H
8
8
5RXQGFDOORXWUHIHUHQFHVDFRPSRQHQW
RQWKHIURQWVLGHRIWKHERDUG
6TXDUHFDOORXWUHIHUHQFHVDFRPSRQHQW
RQWKHEDFNVLGHRIWKHERDUG
8*BB
