Xilinx VCU128 User Manual

Table 8: QDR4 Memory 72-bit I/F to FPGA U1 Banks 68, 69, and 70
FPGA (U1) Pin
Schematic Net
Name
I/O Standard
Component Memory
Pin # Pin Name
QDR4 A-side Data
BM14 QDR4_DQA0 C8 DQA0
BM13 QDR4_DQA1 B7 DQA1
BN15 QDR4_DQA2 C6 DQA2
BN12 QDR4_DQA3 D5 DQA3
BM15 QDR4_DQA4 D7 DQA4
BP13 QDR4_DQA5 A4 DQA5
BP14 QDR4_DQA6 F5 DQA6
BM12 QDR4_DQA7 A6 DQA7
BL15 QDR4_DQA8 A8 DQA8
BM9 QDR4_DQA9 H3 DQA9
BK9 QDR4_DQA10 H5 DQA10
BL10 QDR4_DQA11 J2 DQA11
BK10 QDR4_DQA12 J4 DQA12
BL8 QDR4_DQA13 B2 DQA13
BN10 QDR4_DQA14 E2 DQA14
BM10 QDR4_DQA15 G2 DQA15
BN9 QDR4_DQA16 G4 DQA16
BJ9 QDR4_DQA17 B5 DQA17
BL12 QDR4_DQA18 C12 DQA18
BK14 QDR4_DQA19 B13 DQA19
BJ12 QDR4_DQA20 C14 DQA20
BK15 QDR4_DQA21 D15 DQA21
BL13 QDR4_DQA22 D13 DQA22
BH14 QDR4_DQA23 A16 DQA23
BH15 QDR4_DQA24 F15 DQA24
BJ14 QDR4_DQA25 A14 DQA25
BJ13 QDR4_DQA26 A12 DQA26
BE9 QDR4_DQA27 H17 DQA27
BE10 QDR4_DQA28 H15 DQA28
BG13 QDR4_DQA29 J18 DQA29
BE11 QDR4_DQA30 J16 DQA30
BF10 QDR4_DQA31 B18 DQA31
BG12 QDR4_DQA32 E18 DQA32
BG9 QDR4_DQA33 G18 DQA33
BG10 QDR4_DQA34 G16 DQA34
BF12 QDR4_DQA35 B15 DQA35
Chapter 3: Board Component Descriptions
UG1302 (v1.0) December 21, 2018 www.xilinx.com
VCU128 Board User Guide 30
Send Feedback
