Virtex-6 FPGA Connectivity Kit Getting Started www.xilinx.com 13

UG664 (v1.4) July 6, 2011

Getting Started with the Connectivity Targeted Reference Design Demo

X-Ref Target - Figure 2

Figure 2: ML605 and FMC Connectivity Daughter Card

X-Ref Target - Figure 3

Figure 3: CX4 Connector

UG664_02_022310

Switch S1

J2

J42

Switch S2

UG664_03_022310

CX4 Loopback Connector

J2
