Chapter 1: VC7203 Board Features and Operation
T6 116_RX0_P 116 J84 2,667
T5 116_RX0_N 116 J84 2,668
N4 116_TX1_P 116 J84 2,469
N3 116_TX1_N 116 J84 2,469
R4 116_RX1_P 116 J84 2,207
R3 116_RX1_N 116 J84 2,207
M2 116_TX2_P 116 J84 2,359
M1 116_TX2_N 116 J84 2,357
P6 116_RX2_P 116 J84 2,218
P5 116_RX2_N 116 J84 2,218
L4 116_TX3_P 116 J84 2,555
L3 116_TX3_N 116 J84 2,555
M6 116_RX3_P 116 J84 2,821
M5 116_RX3_N 116 J84 2,821
K2 117_TX0_P 117 J85 2,617
K1 117_TX0_N 117 J85 2,616
K6 117_RX0_P 117 J85 2,886
K5 117_RX0_N 117 J85 2,886
J4 117_TX1_P 117 J85 2,400
J3 117_TX1_N 117 J85 2,401
H6 117_RX1_P 117 J85 2,337
H5 117_RX1_N 117 J85 2,337
H2 117_TX2_P 117 J85 2,635
H1 117_TX2_N 117 J85 2,634
G4 117_RX2_P 117 J85 2,349
G3 117_RX2_N 117 J85 2,349
F2 117_TX3_P 117 J85 2,823
F1 117_TX3_N 117 J85 2,823
F6 117_RX3_P 117 J85 2,873
F5 117_RX3_N 117 J85 2,872
D2 118_TX0_P 118 J86 2,842
D1 118_TX0_N 118 J86 2,844
Table 1-13: GTX Transceiver Pins (Cont’d)
U1 FPGA Pin Net Name Quad Connector
Trace Length
(mils)
