Xilinx Virtex-7 VC7203

VC7203 GTX Transceiver Characterization Board www.xilinx.com 25
UG957 (v1.3) October 17, 2014
Detailed Description
AG6 114_RX0_P 114 J158 2,715
AG5 114_RX0_N 114 J158 2,714
AJ2 114_TX1_P 114 J158 2,180
AJ1 114_TX1_N 114 J158 2,180
AF4 114_RX1_P 114 J158 2,181
AF3 114_RX1_N 114 J158 2,181
AH4 114_TX2_P 114 J158 2,207
AH3 114_TX2_N 114 J158 2,207
AE6 114_RX2_P 114 J158 2,160
AE5 114_RX2_N 114 J158 2,160
AG2 114_TX3_P 114 J158 2,570
AG1 114_TX3_N 114 J158 2,571
AD4 114_RX3_P 114 J158 2,570
AD3 114_RX3_N 114 J158 2,570
Y2 115_TX0_P 115 J83 2,805
Y1 115_TX0_N 115 J83 2,806
AA4 115_RX0_P 115 J83 2,898
AA3 115_RX0_N 115 J83 2,898
V2 115_TX1_P 115 J83 2,525
V1 115_TX1_N 115 J83 2,523
Y6 115_RX1_P 115 J83 2,489
Y5 115_RX1_N 115 J83 2,489
U4 115_TX2_P 115 J83 2,549
U3 115_TX2_N 115 J83 2,549
W4 115_RX2_P 115 J83 2,308
W3 115_RX2_N 115 J83 2,309
T2 115_TX3_P 115 J83 2,840
T1 115_TX3_N 115 J83 2,840
V6 115_RX3_P 115 J83 2,933
V5 115_RX3_N 115 J83 2,933
P2 116_TX0_P 116 J84 2,677
P1 116_TX0_N 116 J84 2,677
Table 1-13: GTX Transceiver Pins (Cont’d)
U1 FPGA Pin Net Name Quad Connector
Trace Length
(mils)
