Xilinx Virtex-7 VC7203

24 www.xilinx.com VC7203 GTX Transceiver Characterization Board
UG957 (v1.3) October 17, 2014
Chapter 1: VC7203 Board Features and Operation
AV8 112_RX0_P 112 J85 2,996
AV7 112_RX0_N 112 J85 2,996
AU2 112_TX1_P 112 J85 2,511
AU1 112_TX1_N 112 J85 2,511
AU6 112_RX1_P 112 J85 2,546
AU5 112_RX1_N 112 J85 2,545
AT4 112_TX2_P 112 J85 2,785
AT3 112_TX2_N 112 J85 2,785
AR6 112_RX2_P 112 J85 2,803
AR5 112_RX2_N 112 J85 2,803
AR2 112_TX3_P 112 J85 3,385
AR1 112_TX3_N 112 J85 3,385
AP8 112_RX3_P 112 J85 3,365
AP7 112_RX3_N 112 J85 3,365
AP4 113_TX0_P 113 J86 2,949
AP3 113_TX0_N 113 J86 2,949
AN6 113_RX0_P 113 J86 3,243
AN5 113_RX0_N 113 J86 3,243
AN2 113_TX1_P 113 J86 2,736
AN1 113_TX1_N 113 J86 2,736
AM8 113_RX1_P 113 J86 2,822
AM7 113_RX1_N 113 J86 2,822
AM4 113_TX2_P 113 J86 2,736
AM3 113_TX2_N 113 J86 2,736
AL6 113_RX2_P 113 J86 2,455
AL5 113_RX2_N 113 J86 2,455
AL2 113_TX3_P 113 J86 2,812
AL1 113_TX3_N 113 J86 2,812
AJ6 113_RX3_P 113 J86 2,892
AJ5 113_RX3_N 113 J86 2,892
AK4 114_TX0_P 114 J158 2,430
AK3 114_TX0_N 114 J158 2,430
Table 1-13: GTX Transceiver Pins (Cont’d)
U1 FPGA Pin Net Name Quad Connector
Trace Length
(mils)
