Chapter 1
VC7203 Board Features and Operation
This chapter describes the components, features, and operation of the VC7203
Virtex®-7 FPGA GTX Transceiver Characterization Board. The VC7203 board provides the
hardware environment for characterizing and evaluating the GTX transceivers available
on the Virtex-7 XC7VX485T-3 FFG1761E FPGA. The VC7203 board schematic,
bill-of-material (BOM), layout files and reference designs are available online at the
Virtex-7 FPGA VC7203 Characterization Kit website
.
FPGA Compatibility
The VC7203 board is provided with Virtex-7 XC7VX485T-3 FFG1761E FPGA. The board
also supports all device densities (i.e., XC7VX330T, XC7V585T, XC7VX690T, XC7V1500T,
and XC7V2000T devices) in the pin-compatible FFG1761, FLG1761, and FHG1761
packages. However, certain interfaces that are available in larger density devices might not
be available in the XC7VX485T device (for example: GTX QUAD_111, GTX QUAD_112,
FMC 3, and so on).
VC7203 Board Features
• Virtex-7 XC7VX485T-3 FFG1761E FPGA
• Onboard power supplies for all necessary voltages
• Power jacks for optional use of external power supplies
• Digilent USB JTAG programming port
• System ACE™ solution Secure Digital (SD) controller
• Power module supporting Virtex-7 FPGA GTX transceiver power requirements
• A fixed, 200 MHz 2.5V LVDS oscillator wired to multi-region clock capable (MRCC)
inputs
• Two pairs of differential MRCC inputs with SMA connectors
• SuperClock-2 module supporting multiple frequencies
• Nine Samtec BullsEye connector pads for the GTX transceivers and reference clocks
•Power status LEDs
• General purpose DIP switches, LEDs, pushbuttons, and test I/O
• Three VITA 57.1 FPGA mezzanine card (FMC) high pin count (HPC) connectors
• USB-to-UART bridge
•I
2
C bus
• PMBus connectivity to onboard digital power supplies
