36 www.xilinx.com VC7203 GTX Transceiver Characterization Board
UG957 (v1.3) October 17, 2014
Chapter 1: VC7203 Board Features and Operation
V30 FMC2_HA02_P K7
V31 FMC2_HA02_N K8
T29 FMC2_HA03_P J6
T30 FMC2_HA03_N J7
W30 FMC2_HA04_P F7
W31 FMC2_HA04_N F8
V29 FMC2_HA05_P E6
U29 FMC2_HA05_N E7
Y29 FMC2_HA06_P K10
Y30 FMC2_HA06_N K11
G36 FMC2_HA07_P J9
G37 FMC2_HA07_N J10
F39 FMC2_HA08_P F10
E39 FMC2_HA08_N F11
J37 FMC2_HA09_P E9
J38 FMC2_HA09_N E10
H38 FMC2_HA10_P K13
G38 FMC2_HA10_N K14
J36 FMC2_HA11_P J12
H36 FMC2_HA11_N J13
P25 FMC2_HA12_P F13
P26 FMC2_HA12_N F14
P22 FMC2_HA13_P E12
P23 FMC2_HA13_N E13
N25 FMC2_HA14_P J15
N26 FMC2_HA14_N J16
N23 FMC2_HA15_P F16
N24 FMC2_HA15_N F17
M27 FMC2_HA16_P E15
L27 FMC2_HA16_N E16
J25 FMC2_HB00_CC_P K25
J26 FMC2_HB00_CC_N K26
H24 FMC2_HB01_P J24
Table 1-19: VITA 57.1 FMC1 HPC Connections at JA3 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
