38 www.xilinx.com VC7203 GTX Transceiver Characterization Board
UG957 (v1.3) October 17, 2014
Chapter 1: VC7203 Board Features and Operation
M32 FMC2_LA01_CC_P D8
L32 FMC2_LA01_CC_N D9
K35 FMC2_LA02_P H7
J35 FMC2_LA02_N H8
J32 FMC2_LA03_P G9
J33 FMC2_LA03_N G10
K33 FMC2_LA04_P H10
K34 FMC2_LA04_N H11
L34 FMC2_LA05_P D11
L35 FMC2_LA05_N D12
M33 FMC2_LA06_P C10
M34 FMC2_LA06_N C11
H34 FMC2_LA07_P H13
H35 FMC2_LA07_N H14
K29 FMC2_LA08_P G12
K30 FMC2_LA08_N G13
J30 FMC2_LA09_P D14
H30 FMC2_LA09_N D15
L29 FMC2_LA10_P C14
L30 FMC2_LA10_N C15
J31 FMC2_LA11_P H16
H31 FMC2_LA11_N H17
M28 FMC2_LA12_P G15
M29 FMC2_LA12_N G16
R28 FMC2_LA13_P D17
P28 FMC2_LA13_N D18
N28 FMC2_LA14_P C18
N29 FMC2_LA14_N C19
R30 FMC2_LA15_P H19
P31 FMC2_LA15_N H20
U31 FMC2_LA16_P G18
T31 FMC2_LA16_N G19
C35 FMC2_LA17_CC_P D20
Table 1-19: VITA 57.1 FMC1 HPC Connections at JA3 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
