VC7203 GTX Transceiver Characterization Board www.xilinx.com 39
UG957 (v1.3) October 17, 2014
Detailed Description
C36 FMC2_LA17_CC_N D21
D35 FMC2_LA18_CC_P C22
D36 FMC2_LA18_CC_N C23
B36 FMC2_LA19_P H22
A37 FMC2_LA19_N H23
B34 FMC2_LA20_P G21
A34 FMC2_LA20_N G22
B39 FMC2_LA21_P H25
A39 FMC2_LA21_N H26
A35 FMC2_LA22_P G24
A36 FMC2_LA22_N G25
C38 FMC2_LA23_P D23
C39 FMC2_LA23_N D24
B37 FMC2_LA24_P H28
B38 FMC2_LA24_N H29
E32 FMC2_LA25_P G27
D32 FMC2_LA25_N G28
B32 FMC2_LA26_P D26
B33 FMC2_LA26_N D27
E33 FMC2_LA27_P C26
D33 FMC2_LA27_N C27
C33 FMC2_LA28_P H31
C34 FMC2_LA28_N H32
G32 FMC2_LA29_P G30
F32 FMC2_LA29_N G31
F36 FMC2_LA30_P H34
F37 FMC2_LA30_N H35
F34 FMC2_LA31_P G33
F35 FMC2_LA31_N G34
H33 FMC2_LA32_P H37
G33 FMC2_LA32_N H38
E37 FMC2_LA33_P G36
Table 1-19: VITA 57.1 FMC1 HPC Connections at JA3 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
