Xilinx Virtex-7 VC7203 User Manual

40 www.xilinx.com VC7203 GTX Transceiver Characterization Board
UG957 (v1.3) October 17, 2014
Chapter 1: VC7203 Board Features and Operation
E38 FMC2_LA33_N G37
G31 FMC2_PRSNT_M2C_L H2
Table 1-20: VITA 57.1 FMC1 HPC Connections at JA4
U1 FPGA Pin Net Name FMC Pin
AY18 FMC3_CLK0_M2C_P H4
AY17 FMC3_CLK0_M2C_N H5
AW18 FMC3_CLK1_M2C_P G2
AW17 FMC3_CLK1_M2C_N G3
H15 FMC3_CLK2_BIDIR_P K4
H14 FMC3_CLK2_BIDIR_N K5
J13 FMC3_CLK3_BIDIR_P J2
H13 FMC3_CLK3_BIDIR_N J3
AU14 FMC3_HA00_CC_P F4
AU13 FMC3_HA00_CC_N F5
AV13 FMC3_HA01_CC_P E2
AW13 FMC3_HA01_CC_N E3
AW12 FMC3_HA02_P K7
AY12 FMC3_HA02_N K8
BA15 FMC3_HA03_P J6
BA14 FMC3_HA03_N J7
AY14 FMC3_HA04_P F7
AY13 FMC3_HA04_N F8
BB14 FMC3_HA05_P E6
BB13 FMC3_HA05_N E7
AV20 FMC3_HA06_P K10
AW20 FMC3_HA06_N K11
BA17 FMC3_HA07_P J9
BB17 FMC3_HA07_N J10
AY20 FMC3_HA08_P F10
BA20 FMC3_HA08_N F11
BA16 FMC3_HA09_P E9
BB16 FMC3_HA09_N E10
Table 1-19: VITA 57.1 FMC1 HPC Connections at JA3 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
Send Feedback

Xilinx Virtex-7 VC7203 Specifications

General

FPGA Family	Virtex-7
Transceiver	GTH
GTH Transceivers	16
Maximum Data Rate	13.1 Gbps
Transceivers	16
Maximum Transceiver Speed	13.1 Gbps
Maximum User I/O	600
Process Technology	28nm
Block RAM	38 Mb
Power Supply Voltage	0.9V
Operating Temperature Range	Industrial
