VC7203 GTX Transceiver Characterization Board www.xilinx.com 43
UG957 (v1.3) October 17, 2014
Detailed Description
AP12 FMC3_LA12_P G15
AR12 FMC3_LA12_N G16
AR15 FMC3_LA13_P D17
AT15 FMC3_LA13_N D18
AT12 FMC3_LA14_P C18
AU12 FMC3_LA14_N C19
AV15 FMC3_LA15_P H19
AV14 FMC3_LA15_N H20
AW15 FMC3_LA16_P G18
AY15 FMC3_LA16_N G19
AT17 FMC3_LA17_CC_P D20
AU17 FMC3_LA17_CC_N D21
AU18 FMC3_LA18_CC_P C22
AV18 FMC3_LA18_CC_N C23
AL19 FMC3_LA19_P H22
AM19 FMC3_LA19_N H23
AK17 FMC3_LA20_P G21
AL17 FMC3_LA20_N G22
AM18 FMC3_LA21_P H25
AM17 FMC3_LA21_N H26
AK19 FMC3_LA22_P G24
AK18 FMC3_LA22_N G25
AM16 FMC3_LA23_P D23
AN16 FMC3_LA23_N D24
AJ18 FMC3_LA24_P H28
AJ17 FMC3_LA24_N H29
AP18 FMC3_LA25_P G27
AP17 FMC3_LA25_N G28
AP20 FMC3_LA26_P D26
AR19 FMC3_LA26_N D27
AN19 FMC3_LA27_P C26
AN18 FMC3_LA27_N C27
AR18 FMC3_LA28_P H31
Table 1-20: VITA 57.1 FMC1 HPC Connections at JA4 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
