Xilinx Virtex-7 VC7203 User Manual

42 www.xilinx.com VC7203 GTX Transceiver Characterization Board
UG957 (v1.3) October 17, 2014
Chapter 1: VC7203 Board Features and Operation
L14 FMC3_HB10_N K32
N16 FMC3_HB11_P J30
M16 FMC3_HB11_N J31
N13 FMC3_HB12_P F31
M13 FMC3_HB12_N F32
N15 FMC3_HB13_P E30
N14 FMC3_HB13_N E31
M12 FMC3_HB14_P K34
M11 FMC3_HB14_N K35
AP13 FMC3_LA00_CC_P G6
AR13 FMC3_LA00_CC_N G7
AR14 FMC3_LA01_CC_P D8
AT14 FMC3_LA01_CC_N D9
AJ16 FMC3_LA02_P H7
AJ15 FMC3_LA02_N H8
AK14 FMC3_LA03_P G9
AK13 FMC3_LA03_N G10
AK15 FMC3_LA04_P H10
AL14 FMC3_LA04_N H11
AJ13 FMC3_LA05_P D11
AJ12 FMC3_LA05_N D12
AL16 FMC3_LA06_P C10
AL15 FMC3_LA06_N C11
AK12 FMC3_LA07_P H13
AL12 FMC3_LA07_N H14
AM13 FMC3_LA08_P G12
AN13 FMC3_LA08_N G13
AM12 FMC3_LA09_P D14
AM11 FMC3_LA09_N D15
AN15 FMC3_LA10_P C14
AN14 FMC3_LA10_N C15
AN11 FMC3_LA11_P H16
AP11 FMC3_LA11_N H17
Table 1-20: VITA 57.1 FMC1 HPC Connections at JA4 (Cont’d)
U1 FPGA Pin Net Name FMC Pin
Send Feedback

Xilinx Virtex-7 VC7203 Specifications

General

FPGA Family	Virtex-7
Transceiver	GTH
GTH Transceivers	16
Maximum Data Rate	13.1 Gbps
Transceivers	16
Maximum Transceiver Speed	13.1 Gbps
Maximum User I/O	600
Process Technology	28nm
Block RAM	38 Mb
Power Supply Voltage	0.9V
Operating Temperature Range	Industrial
