Appendix C: Master Constraints File Listing
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HA13_N]
set_property PACKAGE_PIN N25 [get_ports FMC2_HA14_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HA14_P]
set_property PACKAGE_PIN N26 [get_ports FMC2_HA14_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HA14_N]
set_property PACKAGE_PIN N23 [get_ports FMC2_HA15_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HA15_P]
set_property PACKAGE_PIN N24 [get_ports FMC2_HA15_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HA15_N]
set_property PACKAGE_PIN M27 [get_ports FMC2_HA16_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HA16_P]
set_property PACKAGE_PIN L27 [get_ports FMC2_HA16_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HA16_N]
#FMC2 HB
set_property PACKAGE_PIN J25 [get_ports FMC2_HB00_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB00_CC_P]
set_property PACKAGE_PIN J26 [get_ports FMC2_HB00_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB00_CC_N]
set_property PACKAGE_PIN H24 [get_ports FMC2_HB01_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB01_P]
set_property PACKAGE_PIN G24 [get_ports FMC2_HB01_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB01_N]
set_property PACKAGE_PIN J21 [get_ports FMC2_HB02_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB02_P]
set_property PACKAGE_PIN H21 [get_ports FMC2_HB02_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB02_N]
set_property PACKAGE_PIN H25 [get_ports FMC2_HB03_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB03_P]
set_property PACKAGE_PIN H26 [get_ports FMC2_HB03_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB03_N]
set_property PACKAGE_PIN G21 [get_ports FMC2_HB04_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB04_P]
set_property PACKAGE_PIN G22 [get_ports FMC2_HB04_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB04_N]
set_property PACKAGE_PIN G26 [get_ports FMC2_HB05_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB05_P]
set_property PACKAGE_PIN G27 [get_ports FMC2_HB05_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB05_N]
set_property PACKAGE_PIN K24 [get_ports FMC2_HB06_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB06_CC_P]
set_property PACKAGE_PIN K25 [get_ports FMC2_HB06_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB06_CC_N]
set_property PACKAGE_PIN H23 [get_ports FMC2_HB07_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB07_P]
set_property PACKAGE_PIN G23 [get_ports FMC2_HB07_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB07_N]
set_property PACKAGE_PIN G28 [get_ports FMC2_HB08_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB08_P]
set_property PACKAGE_PIN G29 [get_ports FMC2_HB08_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB08_N]
set_property PACKAGE_PIN K28 [get_ports FMC2_HB09_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB09_P]
set_property PACKAGE_PIN J28 [get_ports FMC2_HB09_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB09_N]
set_property PACKAGE_PIN H28 [get_ports FMC2_HB10_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB10_P]
set_property PACKAGE_PIN H29 [get_ports FMC2_HB10_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC2_HB10_N]
set_property PACKAGE_PIN K27 [get_ports FMC2_HB11_P]
