Xilinx Virtex-7 VC7203 User Manual

VC7203 GTX Transceiver Characterization Board www.xilinx.com 63
UG957 (v1.3) October 17, 2014
VC7203 Board XDC Listing
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA18_CC_N]
set_property PACKAGE_PIN AL19 [get_ports FMC3_LA19_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA19_P]
set_property PACKAGE_PIN AM19 [get_ports FMC3_LA19_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA19_N]
set_property PACKAGE_PIN AK17 [get_ports FMC3_LA20_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA20_P]
set_property PACKAGE_PIN AL17 [get_ports FMC3_LA20_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA20_N]
set_property PACKAGE_PIN AM18 [get_ports FMC3_LA21_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA21_P]
set_property PACKAGE_PIN AM17 [get_ports FMC3_LA21_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA21_N]
set_property PACKAGE_PIN AK19 [get_ports FMC3_LA22_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA22_P]
set_property PACKAGE_PIN AK18 [get_ports FMC3_LA22_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA22_N]
set_property PACKAGE_PIN AM16 [get_ports FMC3_LA23_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA23_P]
set_property PACKAGE_PIN AN16 [get_ports FMC3_LA23_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA23_N]
set_property PACKAGE_PIN AJ18 [get_ports FMC3_LA24_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA24_P]
set_property PACKAGE_PIN AJ17 [get_ports FMC3_LA24_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA24_N]
set_property PACKAGE_PIN AP18 [get_ports FMC3_LA25_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA25_P]
set_property PACKAGE_PIN AP17 [get_ports FMC3_LA25_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA25_N]
set_property PACKAGE_PIN AP20 [get_ports FMC3_LA26_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA26_P]
set_property PACKAGE_PIN AR19 [get_ports FMC3_LA26_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA26_N]
set_property PACKAGE_PIN AN19 [get_ports FMC3_LA27_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA27_P]
set_property PACKAGE_PIN AN18 [get_ports FMC3_LA27_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA27_N]
set_property PACKAGE_PIN AR18 [get_ports FMC3_LA28_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA28_P]
set_property PACKAGE_PIN AR17 [get_ports FMC3_LA28_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA28_N]
set_property PACKAGE_PIN AU19 [get_ports FMC3_LA29_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA29_P]
set_property PACKAGE_PIN AV19 [get_ports FMC3_LA29_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA29_N]
set_property PACKAGE_PIN AT20 [get_ports FMC3_LA30_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA30_P]
set_property PACKAGE_PIN AT19 [get_ports FMC3_LA30_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA30_N]
set_property PACKAGE_PIN AV16 [get_ports FMC3_LA31_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA31_P]
set_property PACKAGE_PIN AW16 [get_ports FMC3_LA31_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA31_N]
set_property PACKAGE_PIN AT16 [get_ports FMC3_LA32_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA32_P]
set_property PACKAGE_PIN AU16 [get_ports FMC3_LA32_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA32_N]
set_property PACKAGE_PIN BB19 [get_ports FMC3_LA33_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA33_P]
