Appendix C: Master Constraints File Listing
set_property PACKAGE_PIN BB18 [get_ports FMC3_LA33_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_LA33_N]
#FMC2 HA
set_property PACKAGE_PIN AU14 [get_ports FMC3_HA00_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA00_CC_P]
set_property PACKAGE_PIN AU13 [get_ports FMC3_HA00_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA00_CC_N]
set_property PACKAGE_PIN AV13 [get_ports FMC3_HA01_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA01_CC_P]
set_property PACKAGE_PIN AW13 [get_ports FMC3_HA01_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA01_CC_N]
set_property PACKAGE_PIN AW12 [get_ports FMC3_HA02_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA02_P]
set_property PACKAGE_PIN AY12 [get_ports FMC3_HA02_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA02_N]
set_property PACKAGE_PIN BA15 [get_ports FMC3_HA03_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA03_P]
set_property PACKAGE_PIN BA14 [get_ports FMC3_HA03_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA03_N]
set_property PACKAGE_PIN AY14 [get_ports FMC3_HA04_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA04_P]
set_property PACKAGE_PIN AY13 [get_ports FMC3_HA04_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA04_N]
set_property PACKAGE_PIN BB14 [get_ports FMC3_HA05_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA05_P]
set_property PACKAGE_PIN BB13 [get_ports FMC3_HA05_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA05_N]
set_property PACKAGE_PIN AV20 [get_ports FMC3_HA06_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA06_P]
set_property PACKAGE_PIN AW20 [get_ports FMC3_HA06_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA06_N]
set_property PACKAGE_PIN BA17 [get_ports FMC3_HA07_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA07_P]
set_property PACKAGE_PIN BB17 [get_ports FMC3_HA07_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA07_N]
set_property PACKAGE_PIN AY20 [get_ports FMC3_HA08_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA08_P]
set_property PACKAGE_PIN BA20 [get_ports FMC3_HA08_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA08_N]
set_property PACKAGE_PIN BA16 [get_ports FMC3_HA09_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA09_P]
set_property PACKAGE_PIN BB16 [get_ports FMC3_HA09_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA09_N]
set_property PACKAGE_PIN AY19 [get_ports FMC3_HA10_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA10_P]
set_property PACKAGE_PIN BA19 [get_ports FMC3_HA10_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA10_N]
set_property PACKAGE_PIN C16 [get_ports FMC3_HA11_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA11_P]
set_property PACKAGE_PIN B16 [get_ports FMC3_HA11_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA11_N]
set_property PACKAGE_PIN B14 [get_ports FMC3_HA12_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA12_P]
set_property PACKAGE_PIN A14 [get_ports FMC3_HA12_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA12_N]
set_property PACKAGE_PIN C15 [get_ports FMC3_HA13_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA13_P]
set_property PACKAGE_PIN C14 [get_ports FMC3_HA13_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA13_N]
