Xilinx Virtex-7 VC7203 User Manual

VC7203 GTX Transceiver Characterization Board www.xilinx.com 65
UG957 (v1.3) October 17, 2014
VC7203 Board XDC Listing
set_property PACKAGE_PIN D13 [get_ports FMC3_HA14_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA14_P]
set_property PACKAGE_PIN C13 [get_ports FMC3_HA14_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA14_N]
set_property PACKAGE_PIN D16 [get_ports FMC3_HA15_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA15_P]
set_property PACKAGE_PIN D15 [get_ports FMC3_HA15_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HA15_N]
#FMC2 HB
set_property PACKAGE_PIN G14 [get_ports FMC3_HB00_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB00_CC_P]
set_property PACKAGE_PIN G13 [get_ports FMC3_HB00_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB00_CC_N]
set_property PACKAGE_PIN F16 [get_ports FMC3_HB01_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB01_P]
set_property PACKAGE_PIN E15 [get_ports FMC3_HB01_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB01_N]
set_property PACKAGE_PIN E14 [get_ports FMC3_HB02_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB02_P]
set_property PACKAGE_PIN E13 [get_ports FMC3_HB02_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB02_N]
set_property PACKAGE_PIN H16 [get_ports FMC3_HB03_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB03_P]
set_property PACKAGE_PIN G16 [get_ports FMC3_HB03_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB03_N]
set_property PACKAGE_PIN G12 [get_ports FMC3_HB04_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB04_P]
set_property PACKAGE_PIN F12 [get_ports FMC3_HB04_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB04_N]
set_property PACKAGE_PIN K12 [get_ports FMC3_HB05_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB05_P]
set_property PACKAGE_PIN J12 [get_ports FMC3_HB05_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB05_N]
set_property PACKAGE_PIN F15 [get_ports FMC3_HB06_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB06_CC_P]
set_property PACKAGE_PIN F14 [get_ports FMC3_HB06_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB06_CC_N]
set_property PACKAGE_PIN K15 [get_ports FMC3_HB07_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB07_P]
set_property PACKAGE_PIN J15 [get_ports FMC3_HB07_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB07_N]
set_property PACKAGE_PIN K14 [get_ports FMC3_HB08_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB08_P]
set_property PACKAGE_PIN K13 [get_ports FMC3_HB08_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB08_N]
set_property PACKAGE_PIN L16 [get_ports FMC3_HB09_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB09_P]
set_property PACKAGE_PIN L15 [get_ports FMC3_HB09_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB09_N]
set_property PACKAGE_PIN M14 [get_ports FMC3_HB10_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB10_P]
set_property PACKAGE_PIN L14 [get_ports FMC3_HB10_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB10_N]
set_property PACKAGE_PIN N16 [get_ports FMC3_HB11_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB11_P]
set_property PACKAGE_PIN M16 [get_ports FMC3_HB11_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB11_N]
set_property PACKAGE_PIN N13 [get_ports FMC3_HB12_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC3_HB12_P]
Send Feedback

Xilinx Virtex-7 VC7203 Specifications

General

FPGA Family	Virtex-7
Transceiver	GTH
GTH Transceivers	16
Maximum Data Rate	13.1 Gbps
Transceivers	16
Maximum Transceiver Speed	13.1 Gbps
Maximum User I/O	600
Process Technology	28nm
Block RAM	38 Mb
Power Supply Voltage	0.9V
Operating Temperature Range	Industrial
