Chapter 3: Board Component Descriptions
The ZCU104 evaluation board uses both PMBus compliant POL controllers and no-PMBus
regulators from Infineon Technologies [Ref 22] to supply the core and auxiliary voltages
listed in Table 3-31. The schematic page references are to 0381794.
The FMC LPC (J5) VADJ pins are wired to the programmable rail VADJ_FMC. The VADJ_FMC
rail is programmed to 1.80V by default. The valid values of the VADJ_FMC rail are 1.2V, 1.5V,
and 1.8V. The VADJ_FMC rail also powers the XCZU7EV HP banks 67 and 68 (see Table 3-2,
page 23).
Documentation describing PMBus programming for the Infineon Technologies PMIC
flexible power management unit power controllers is available at the Infineon Technologies
website [Ref 22]. The PCB layout and power system design meets the recommended criteria
described in the UltraScale Architecture PCB Design User Guide (UG583) [Ref 4].
Table 3-31: Power System Devices
Device Type
Ref.
Des.
PMBus
Addr.
I2C
Addr.
Description Output
Power Rail
Net Name
Power
Rail
Voltage
Max.
Current
Schem.
Page
IRPS5401MTRPBF U179 0x43 0x13
Infineon
IRPS5401
multi-output
PMIC
PHASE_A VCCINT 0.85V
47
PHASE_B VCC1V8 1.80V
PHASE_C
VCC1V2 1.20V
PHASE_D
LDO MGTAVCC 0.85V
IRPS5401MTRPBF U180 0x44 0x14
Infineon
IRPS5401
multi-output
PMIC
PHASE_A UTIL_3V3 3.30V
49
PHASE_B VCC1V13 1.13V
PHASE_C UTIL_5V0 5.00V
PHASE_D VADJ_FMC 1.80V
LDO MGTRAVCC 0.85V
IR3883MTRPBF U173 NA NA
POL
Switching
regulator
SW VCC3V3 3.30V 3A 51
IR3823MTRPBF U171 NA NA
Switching
regulator
SW MGT1V2 1.20V 3A 52
IFX54441LDV U174 NA NA
Low noise
LDO
OUT MGT1V8 1.81V 500 mA 53
IR3883MTRPBF U172 NA NA
POL
switching
regulator
SW UTIL_2V5 2.50V 3A 54
IR3897MTRPBF U177 NA NA
Source-sink
switching
regulator
SW PL_DDR4_VTT 0.60V 4A 55
IR3897MTRPBF U178 NA NA
Source-sink
switching
regulator
SW PS_DDR4_VTT 0.60V 4A 55
Send Feedback
