Xinje XC Series User Manual

 I/O expansions list:
①
For Expansion
E
②
Analogue Input
4AD：4CH analogue input
8AD：8CH analogue input
③
Analogue Output
2DA：2CH analogue output
4DA：4CH analogue output
④
PT100 Temperature
6PT：6CH PT100
⑤
K type thermocouple
6TCA：6CH thermocouple input (V3.1or above)
⑥
P、I、D tune
P：with PID tune
Blank：without PID tune
 Analogue、temperature modules list:
Model
I/O
Points
Input
points
(DC24V)
Output
points
(R, T)
Input
Output
relay output
transistor output
N
P
N
XC-E8X
-
-
8
8
-
-
XC-E8YR
XC-E8YT
8
-
8
-
XC-E8X8YR
XC-E8X8YT
16
8
8
XC-E16X
-
-
16
16
-
-
XC-E16YR
XC-E16YT
16
-
16
-
XC-E16X16YR
XC-E16X16YT
32
16
16
XC-E32X
-
-
32
32
-
-
XC-E32YR
-
32
-
32
P
N
P
XC-E8PX
-
-
8
8
-
-
XC-E8YR
XC-E8YT
8
-
8
-
XC-E8PX8YR
XC-E8PX8YT
16
8
8
XC-E16PX
-
-
16
16
-
-
XC-E16YR
XC-E16YT
16
-
16
-
XC-E16PX16YR
XC-E16PX16YT
32
16
16
XC-E32PX
-
-
32
32
-
-
XC-E32YR
-
32
-
32
Analogue &Temperature
Expansion
2
Analogue、Temperature model name Principle:
XC－E 4AD 4DA 6PT 6TCA – P
① ② ③ ④ ⑤ ⑥
