Xinje XC Series User Manual

8 expansion devices
CH
NAME
SIGNAL
CH0
AO0
Current analogue output
VO0
Voltage analogue output
C0
COM of CH0
CH1
AO1
Current analogue output
VO1
Voltage analogue output
C1
COM of CH1
-
24V
+24V power supply
0V
COM of power supply
8-3-6．XC-E6PT-P
※1: If no signal input, the value is 3500;
※2: According to the actual requirements, connect with Pt100 resistors
Items
Content
Analogue Input Signal
Pt100 resistor
Temperature testing range
-100℃～350℃
Digital Output range
-1000～3500, 16bits with sign, binary
Control precision
±0.5℃
Distinguish Ratio
0.1℃
Integral Precision
0.8% (Relate to the max value)
Convert Speed
20ms/CH
Power Supply
DC24V±10%，50mA
Brief Introduction
1
Specification
2
 Pt resistor input, the scale is Pt100
 6CH input, 6CH output, 2 groups PID parameters (3CH/group)
 1mA constant output, doesn’t effected by the environment;
 The distinguish precision is 0.1℃
 As the special module, 7pcs XC-E6PT-P can be connected to one XC series PLC main unit;
